2-14 Chapter 2: Getting started
2.4.6 CPU Offset Mode Sign [+]
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
CPU Voltage [Auto]
Allows you to set the CPU Offset voltage. The values range from -0.1V to +0.5V with a
0.00625V interval.
Refer to the CPU documentation before setting the CPU voltage. Setting a high voltage
may damage the CPU permanently, and setting a low voltage may make the system
unstable.
VDDNB Offset Mode Sign [+]
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
VDDNB Voltage [Auto]
Allows you to set the VDDNB Offset voltage. The values range from -0.1V to +0.5V with a
0.00625V interval.
2.4.7 DRAM Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 1.35V to 2.13V with a 0.01V
increment and 0.05V decrement.
2.4.8 SB 1.1V Voltage [Auto]
Allows you to set the Southbridge 1.1V voltage. The values range from 1.1V to 1.3V with a
0.01V increment.
2.4.9 APU1.8V Voltage [Auto]
Allows you to set the APU (Accelerated Processor Unit) 1.8V voltage. The values range from
1.8000V to 1.9000V with a 0.1V interval.
• The values of the CPU Voltage, VDDNB Voltage, DRAM Voltage, SB 1.1V Voltage,
and APU1.8V Voltage items are labeled in different color, indicating the risk levels of
high voltage settings.
• The system may need better cooling system to work stably under high voltage
settings.
2.4.10 APU Spread Spectrum [Auto]
[Auto] Automatic configuration.
[Disabled] Enhances the PCIE overclocking ability.
[Enabled] Sets to [Enabled] for EMI control.
•
•
•
•
•
•
•
