Page 28

USB 3.0 ports 1 and 2. These two 9-pin Universal Serial Bus (USB) ports are for USB

3.0/2.0 devices.

•

DO NOT connect a keyboard / mouse to any USB 3.0 port when installing Windows

operating system.

•

Due to USB 3.0 controller limitation, USB 3.0 devices can only be used under

Windows

OS environment and after the USB 3.0 driver installation.

•

USB 3.0 devices can only be used as data storage only.

•

We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster

and better performance for your USB 3.0 devices.

10. eSATA port. This port connects to an external Serial ATA hard disk drive.
11. DVI-I port. This port is for any DVI-I compatible device and are HDCP compliant,

allowing playback of HD DVD, Blu-Ray and other protected content.

12. HDMI port. This port is for a High-Definition Multimedia Interface (HDMI) connector,

and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected

content.

13. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports are for USB

2.0/1.1 devices.

Refer to the audio configuration table below for the function of the audio ports in the 2, 4, 6,

or 8-channel configuration.

Audio 2, 4, 6, 8-channel configuration

Port

Headset

2-channel

4-channel

6-channel

8-channel

Light Blue (Rear panel)

Line In

Rear Speaker Out

Lime (Rear panel)

Line Out

Front Speaker Out Front Speaker Out

Front Speaker Out

Pink (Rear panel)

Mic In

Bass/Center

Lime (Front panel)

Side Speaker Out

To configure an 8-channel audio output:

Use a chassis with HD audio module in the front panel to support an 8-channel audio

output.

Chapter 1: Product introduction

1-16
