34
Actiontec USB/Ethernet DSL Modem User Manual
35
Chapter 6 Configuring Advanced Settings
Beginning IP Address, Ending IP Address
These are the
IP addresses at which the DHCP server starts and stops assigning IP
addresses. Actiontec recommends keeping the factory default settings for these IP
addresses (192.168.0.2 and 192.168.0.254, respectively).
The beginning and ending
IP addresses define the IP address range of the
Modem. If the default values are left intact, the Modem supplies a unique IP
address between 192.168.0.2 and 192.168.0.254
to each computer on the net-
work. Note that the first three groups of numbers of the addresses are identical;
this means they are on the same subnet. The
IP address of the Modem must
be on the same subnet as the IP address range it generates. For instance, if the
Modem’s IP address is changed to 10.33.222.1, set the beginning IP address to
10.33.222.2, and the ending IP address to 10.33.222.254.
DNS (Dynamic or Static)
This is the type of
DNS server provided by the ISP . If the ISP provided DNS server
information, select the type here. If not, leave as is.
DNS Server 1
The primary
DNS server provided by the ISP . If the ISP provided DNS server
information, enter it here. If not, leave the text box intact.
DNS Server 2
The secondary
DNS provided by the ISP . If the ISP provided secondary DNS
server information, enter it here. If not, leave the text box intact.
LAN IP Address
Selecting LAN IP Address in the Advanced Setup tab generates a“Warning” screen.
After reading the on-screen information, click Yes.
