5-16 Chapter 5: BIOS setup
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Compatible Mode [Disabled]
This item only appears when you set the SATA Mode Selection to [IDE]. This item allows you to
enable or disable the Compatible mode. Configuration options: [Disabled] [Enabled]
SATA Controller(s) [Enabled]
SATA Mode Selection [IDE]
Compatible Mode [Disabled]
S.M.A.R.T. Status Check [Enabled]
Serial SATA Port 0 HardDisk (250.0GB)
Software Preserve SUPPORTED
Serial SATA Port 1 HardDisk (250.0GB)
Software Preserve SUPPORTED
Serial SATA Port 2 HardDisk (250.0GB)
Software Preserve SUPPORTED
Serial SATA Port 3 HardDisk (250.0GB)
Software Preserve SUPPORTED
Serial SATA Port 4 HardDisk (250.0GB)
Software Preserve SUPPORTED
Serial SATA Port 5 ASUS DVD-E8 ATAPI
Software Preserve SUPPORTED
Determines how SATA
controller(s) operate.
5.4.4 System Agent (SA) Configuration
This allows you to change System Agent parameters.
VT-d [Enabled]
This allows you enable or disable the VT-d function on MCH. Configuration options: [Enabled]
[Disabled]
System Agent Bridge Name Haswell
System Agent RC Version 1.0.0.0
VT-d Capability Supported
VT-d [Enabled]
Enable NB Card [Disabled]
BDAT ACPI Table Support [Disabled]
VGA Priority [Offboard]
Memory Configuration
Check to enable VT-d
function on MCH.
Enable NB CRID [Disabled]
This allows you enable or disable the NB CRID WorkAround. Configuration options: [Enabled]
[Disabled]
BDAT ACPI Table Support [Disabled]
This allows you enable or disable the support for the BDAT ACPI table. Configuration options:
[Enabled] [Disabled]
VGA Priority [Offboard]
This allows you to prioritize between the onboard and offboard video device to be found.
Configuration options: [Onboard] [Offboard]
