Asus TS300-E8-PS4 - Manual (Page 16)

Chapter 1: Product introduction 1-4
*Specifications are subject to change without notice.
TS300-E8-PS4
Auxiliary Storage
FDD / CD / DVD
3 x 5.25-inch media bays
Options:
1. No Device
2. With DVD-RW for North America
Onboard I/O
5 x RJ-45 ports (One for ASMB7-iKVM)
4 x USB 3.0 ports (Front x 2, Rear x 2)
4 x USB 2.0 ports (Front x 2, Rear x 2)
1 x Internal A Type USB port
1 x VGA port
1 x PS/2 keyboard/mouse port
Management
Solution
Out of Band
Remote
Management
Optional ASMB7-iKVM for KVM-over-IP support
Software ASWM Enterprise
Dimension
(HH x WW x DD)
445mm x 217.5mm x 545mm
Net Weight Kg
(CPU, DRAM, & HDD
not included)
20 Kg
Environment
Operation temperature : 10°C–40°C
Non operation temperature: -40°C–70°C
Non operation humidity : 20% ~ 90% (Non-condensing)
Power Supply 500W(80Plus) Bronze Single Power Supply
Power Rating 100-240V, 10A-6A, 50-60Hz, Class I
TS300-E8-PS4 Technical Specifications:
