ASUS TS300-E8-PS4 1-5
1.4 Front panel features
The barebone server displays a simple yet stylish front panel with easily accessible features.
The power and reset buttons, LED indicators, optical drive, and four USB ports are located on
the front panel.
The drive bays, power and reset buttons, LED indicators, DVD-ROM drive, USB 2.0 and the
USB 3.0 ports are located on the front panel. For future installation of 5.25-inch devices, two
drive bays are available.
1. Refer to section 1.7.1 Front panel LEDs for the LED descriptions.
2. * The Headset and Mic In ports are only available when a MIO card
is installed.
Optical drive
Empty 5.25-inch
bays
Power button
Reset button
Message LED
HDD access LED
Power LED
USB 2.0 ports
Security lock
4-bay HDD cage
LAN1 LED
LAN2 LED
USB 3.0 ports
4-bay HDD cage
(Optional Set)
Locate LED
Headset port*
Mic In port*
