ASUS TS300-E8-PS4
4-5
Internal connectors
Page
1.
Serial ATA 6.0/3.0 Gbps connector
(7-pin SATA 6Gbps 1-4 connector [Light Blue])
(7-pin SATA 3Gbps 5-6 connector [Black])
4-17
2.
PSAS connectors
(7-pin PSAS1, PSAS2, PSAS3, PSAS4, PSAS5, PSAS6, PSAS7,
PSAS8 [Light Blue])
4-18
3.
Hard disk activity LED connector (4-pin HDLED1)
4-18
4.
USB 2.0 connector (10-1 pin USB78; A-Type USB9)
4-19
5.
USB 3.0 connector (20-1 pin USB3_34)
4-19
6.
Thermal sensor cable connectors (3-pin TR1)
4-20
7.
CPU, front, and rear fan connectors
(4-pin CPU_FAN1, FRNT_FAN1, FRNT_FAN2, FRNT_FAN3,
REAR_FAN1)
4-20
8.
Serial General Purpose Input/Output connector
(6-1 pin SGPIO1)
4-21
PIKE Serial General Purpose Input/Output connectors
(8-1 pin PSGPIO1/2)
4-21
9.
Serial port connectors (10-1 pin COM1/COM2)
4-22
10.
Power Supply SMBus connector (5-pin PSUSMB1)
4-22
11.
Trusted Platform Module connector (20-1 pin TPM1)
4-23
12.
SATA DOM power connector (4-pin PWR3)
4-23
13.
ATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1)
4-24
14.
System panel connector (20-1 pin PANEL1)
4-25
15.
Auxiliary panel connector (20-2 pin AUX_PANEL1)
4-26
