254
Using Optional Accessories
7
Set the white balance to [h]
(= 134).
8
Enter <e> mode (= 142).
9
Set [ND Filter] to [On] (= 133).
10
Configure the external flash.
z Follow step 5 on = 251 to adjust the
settings.
• Keep the macro ring lite cord away from flash heads.
• When using a tripod, adjust the position of the legs to prevent
them from coming into contact with the flash heads or the bracket.
• Use the screen to compose shots, because the viewfinder cannot
be used with these accessories attached.
Macro Twin Lite MT‑24EX
These optional flash units enable many styles of macro flash photography.
Requires the Conversion Lens Adapter LA-DC58L, Off-Camera Shoe Cord
OC-E3, and Bracket BKT-DC1 (all sold separately) for attachment to the
camera.
1
Remove the ring and attach the
back section of the conversion
lens adapter.
z Follow steps 1 – 3 on = 252 – 253 to
remove the ring, and then attach the back
section of the conversion lens adapter.
2
Attach the off-camera shoe cord
to the bracket.
z Slide the bracket screw to the outer end
of the bracket. Align the bracket screw
with the tripod socket of the off-camera
shoe cord, and then tighten the screw to
secure it.
