Axis Communications 2120 User Manual
Page 22
Installing Your Camera to a Modem
AXIS 2120 User’s Manual
22
Creating a Dial-up Networking Connection...
Follow the steps below to create a dedicated dial-up networking connection to your AXIS 2120:
❶
Double-click My Computer
and then double click the
Dial-Up Networking icon.
❷
Double-click the Make
New Connection icon.
❹
From the drop down
dialog, select the Standard
Modem previously created
for the AXIS 2120 as the
selected device. Click
Configure...
❺
To significantly
improve the
performance of your
AXIS 2120 when using
the Null Modem cable,
set the Maximum Speed
to 115200.
❽
You have now successfully created
your dedicated dial-up networking
connection for your AXIS 2120.
Click Finish.
❼
The telephone numbers requested
in the following dialog are not required
for use in the logical connection to
your camera. To bypass the wizard
error correction, simply enter any
dummy number into the Area code,
Telephone number and Country code
fields. Click Next>.
❻
Click OK to return to the
Make New Connection dialog.
Click Next>.
The new dial-up network
connection is displayed. You
are now ready to refine the
dial-up networking
properties, as described in
the next section...
❸
Provide the connection
with a name (AxisCamera is
the name used in the
subsequent examples).
