Installing Your Camera on a Network AXIS 2120 User’s Manual 12
Installing Your Camera on a Network
• Macintosh users - Please refer to Notes for Macintosh Users, on page 18.
• Easy installation - Use The AXIS IP Installer. See Using the AXIS IP Installer, on page 16.
• Quick installation- Follow the instructions below to install the AXIS 2120 on an Ethernet network.
Important!
Quick Installation Procedure
Follow the instructions below to quickly install the AXIS 2120 onto an Ethernet network:
❶ Note the Serial number
Note the Serial number on the underside of the unit. You need to know this to set the IP address:
❷
Assign an IP Address
Using an appropriate method for your operating system, assign your AXIS 2120 with a unique IP
address from a computer on your network, using the ARP command, as follows:
You will now see ‘
Request timed out...
’ messages repeatedly returned in the window.
• For details on how to install the AXIS 2120 to a modem, see Installing Your Camera to a Modem, on page 19.
• If you are using your AXIS 2120 in an outdoor application, the unit must be housed in an outdoor enclosure.
Please see the Axis Website at: www.axis.com for suppliers details.
• Do not use the default or IP address featured in the following examples when installing your AXIS 2120.
Acquire an unused IP address from your Network Administrator.
• Server Privileges: Although no special privileges are required for Windows 95/98, you do need Administrator
privileges for Windows NT/2000, and Root privileges on UNIX.
00-40-8c-10-00-86
Serial number same as
Ethernet number; e.g.
00408c100086 =
Windows 95/98 & NT/2000 only - Start a DOS
window and type these commands:
Syntax:
arp -s
ping -t -t
Example:
arp -s 172.21.1.200 00-40-8c-10-00-86 172.21.1.193
ping -t 172.21.1.200 -t
UNIX only - Type these commands in
your command line:
Syntax:
arp -s temp
ping
Example:
arp -s 172.21.1.200 00:40:8c:10:00:86 temp
ping 172.21.1.200
