Brother PT-9500PC - Manual (Page 98)

97
Cre
atin
g l
ab
els:
Ma
ci
ntos
h
ve
rs
ion
■ Object dock
The object dock contains icons to add
illustrations and likenesses to a label.
" Bar Code
Set up a bar code.
" Clip Art
Retrieve various illustrations.
" Arrange Text
Change the shape of the lines of text.
" Make Picture
Assemble different elements to create an
illustration.
" Image
Retrieve a saved illustration or photograph.
" Date and Time
The current date and time can be
displayed as a line of text.
" Merge Database Field
Make a database field.
Creating a name badge
The chapter contains an example of creating a
nametag using Mac OS 8.6-9.x.
1
Start P-touch Editor.
2
Click .
→The page properties box appears.
3
Set the label length to 4" (100 mm).
4
Set the label width to 1" (24 mm).
5
Click in the page property box.
→The printing orientation will be set to
landscape orientation.
6
Click .
→The font properties box appears.
7
In the font box, select Atlanta.
