ASSEMBLY INSTRUCTIONS for BUSHMAN, DELUXE, & ELITE MODELS
PREPARATION FOR ASSEMBLY: Removing parts from carton and some assembly will require
two people. Before starting assembly, read the instructions and your manual.
This manual covers several Bushman Grill models. Use only the steps that pertain to your model.
Remove all the parts from the carton and lay them on a smooth, clean surface. (You may cut the car-
ton, spread it out, and use it as a pad to protect part finishes.) Look in the Parts List below under your
model number to find the exact parts you need. Do not throw away any packaging until you have locat-
ed all the parts.
Follow instructions of each step in the order they are written as you look at the diagrams. This will allow
little confusion and easier assembly.
If you have any questions which require help, contact Customer Service and be sure to mention the
model number of your grill.
1
2
3
4
5
6
7
8
9
10
PART#
End Caps - Oval
End Caps - Round
Legs, Fixed Oval
Legs, Fixed - Tubular
Clip, Cylinder Retainer
Bottom Shelf
Cylinder Support
Bolt, M6 x 15
Nut, M6
Legs, Wheel - Oval
03.6201.00
03.6202.00
03.6203.00
03.6204.00
03.6205.00
03.6206.00
03.6207.00
03.6208.00
03.6209.00
03.6210.00
BUSHMAN
2
1
1
1
1
11
39
BUSHMAN
DELUXE
2
1
1
1
1
11
39
1
BUSHMAN
ELITE
2
1
1
1
1
11
39
1
PART/ DESCRIPTION
6
