Aussie Bushman User Manual
Page 17
STEP 9 - Mount Grill bowl to Legs
17
•Carefully position grill Bowl over holes in tops of Legs with the Burner manifold tubes facing forward
opposite the Rear Support Bar at the back of cart. (The Cylinder Support Bracket should be on the
left side.)
•Insert a M6 x 45mm Bolt through a 6mm Washer. Carefully align a Bowl Bolt Spacer between Bowl
and Leg underneath one of the four holes in each corner of the bowl. Insert a M6 x 45mm Bolt
through Bowl, Bowl Bolt Spacer and Leg and secure with a 6M Nut. (See Photos 2 & 3) Repeat with
remaining Bolts.
(ITEM 13)
BOLT, M6 X 45
4 pcs
(ITEM 27)
WASHER 6MM
4 pcs
(ITEM 26)
BOWL BOLT SPACER
4 pcs
(ITEM 9)
NUT, 6M
4 pcs
TOOLS:
6M x 45 Bolt
Bowl Bolt
Spacer
6M Nut
*Caution* - DO NOT Overtighten
mounting screws. You could crack
the porcelain Bowl.
Photo 1
Photo 2
Photo 3
