Continued: STEP 10 - Attach Control Panel

STEP 11 - Attach Igniter Wire

•Attach Control Panel : Insert gas outlet tubes on back of Control Panel into Burner manifold tubes.

(See Photo 1 below) Secure Control Panel to Cart by inserting bolts through holes on outside tops
of front legs. When Control Panel and Burner are correctly aligned, tighten all bolts.

•Attach Igniter Wire : Push electrode connector

at end of Igniter wire onto center tab on rear
of Igniter Button.

•NOTE: Be sure to route electrode wire away

from hot areas of the grill.

BUSHMAN™ ELITE

(ITEM 13)

BOLT, M6 X 45

4 pcs

(ITEM 9)

NUT 6M

4 pcs

TOOLS:

(ITEM 28)

CONTROL PANEL

BUSHMAN™ & BUSHMAN™

DELUXE

Photo 1
