Aussie Bushman - Manual (Page 11)

STEP 2- Attach Legs to Bottom Shelf
TOOLS:
11
•Attach Legs to Bottom Shelf as shown using M6 x 50mm Bolts (M6 x 45mm for Bushman.) Note that
the Wheel Legs (that have axle holes at the bottom) attach on the same side of the Bottom Shelf as
the Cylinder Support. Position legs so that the velcro patches and/ or the four Bolt holes on the back
leg face to the rear.
(ITEM 10, 11)
WHEEL LEGS
(ITEM 12)
BOLT, M6 X 50
8 pcs
(ITEM 13)
BOLT, M6 X 45
8 pcs
(ITEM 9)
NUT, M6
8 pcs
Velcro patches on
this side.
(ITEM 3 OR 4)
LEGS, FIXED
Velcro
Patches on
back side
of Front
Leg Deluxe
and Elite
Models
only.
Velcro
Patches on
back side
of Front
Leg Deluxe
and Elite
Models
only.
Wheel Leg
Four
Bolt
Holes
here
on
back
leg
Four
Bolt
Holes
here on
back
leg
Wheel
Leg
Axle
holes
