Aussie Bushman User Manual
Page 24
STEP 17 - Elite Right Side Burner
(BUSHMAN ELITE MODELS ONLY)
24
•With Left Side Table installed in Step 16, begin installation of the Right Side Burner Table. If you do
not have a Side Burner Table skip to Step 18.
•Insert Side Table Burner Tube onto Side Burner Nozzle as shown below. Using four 6M x 45mm
Bolts, 6M nuts, and Side Table Spacers attach Burner Side Table to Cart. (See Photos 1 & 2 below)
•Connect Igniter Wire to side tab on Igniter Button as shown below. ( See Photo 3)
•Lay Side Table Grid into place using provided holes in top of Side Table. Insert Side Burner Cover
hinges into slots at the back of the Side Burner Table so that the cover swings up and down freely.
(See Photo 4)
(ITEMS 42, 43,
44, 45, 46, & 47)
SIDE BURNER
ASSEMBLY
(ITEM 53 )
SIDE TABLE GRID
TOOLS:
(ITEM 48)
SIDE BURNER
COVER
Connect Igniter Wire to side tab on Igniter
Side Burner Tube
Side Burner
Nozzle
Note: Burner Side Table does
not fold down for storage
Photo 1
Photo 2
Photo 3
Photo 4
