- 27 -
5.10 Common parameter setting mode SET 12
SET12 Name Setting content Initial value
1 PRT Communication protocol setting
Press the MODE key for making a setting effective.
0
0 TOHO protocol
1 MODBUS protocol (RTU mode)
2 MODBUS protocol (ASCII mode)
2 COM Communication parameter
***1 1 bit
B8N2
***2 2 bits
**N* None
**O* Odd No.
**E* Even No.
*7** 7 bits For MODBUS(RTU) setting, 7bits is ineffective
*8** 8 bits
N*** Nonexistent (settable for TOHO protocol)
B*** Existent (settable for TOHO protocol)
3 BPS Communication speed setting
2.4 2400 bps
9.6
4.8 4800 bps
9.6 9600 bps
19.2 19200 bps
38.4 38400 bps
4 ADR Communication address setting
TOHO protocol 1 to 99 (stations)
1
MODBUS protocol 1 to 247 (stations)
5 AWT Communication response delay time setting 0 to 250 (ms) 0
6 MOD Communication switchover setting 0 Write inhibit 1 Writable 1
7 SLV Number-of-sub-controller-connections setting (*2) 0 to 10 (unit) 0
5.11 Common parameter setting mode SET 13
SET13 Name Setting content Initial value
1 LOC-1 Normal screen lock setting
During the lock ON, an attempt of changing a
setting results in “LOC” displayed on the screen.
0
2 LOC-2 Pattern No. setting mode lock setting
3 LOC-3 Alarm temperature setting mode lock setting 0 Lock turned off
4 LOC-4 PID setting mode lock setting 1 Lock turned on
5 LOC01 Common parameter setting mode SET01 lock setting
6 LOC02 Common parameter setting mode SET02 lock setting
7 LOC03 Common parameter setting mode SET03 lock setting
8 LOC04 Common parameter setting mode SET04 lock setting
9 LOC05 Common parameter setting mode SET05 lock setting
10 LOC06 Common parameter setting mode SET06 lock setting
11 LOC07 Common parameter setting mode SET07 lock setting
12 LOC08 Common parameter setting mode SET08 lock setting
13 LOC09 Common parameter setting mode SET09 lock setting
14 LOC10 Common parameter setting mode SET10 lock setting
15 LOC11 Common parameter setting mode SET11 lock setting
16 LOC12 Common parameter setting mode SET12 lock setting
17 LOCS1 Setting temperature (All steps in a batch)
18 LOCS2 Wait function setting (All steps in a batch)
19 LOCS3 Time signal 1 function setting (All steps in a batch)
20 LOCS4 Time signal 2 function setting (All steps in a batch)
21 LOCS5 Time signal 3 function setting (All steps in a batch)
22 LOCS6 Time signal 4 function setting (All steps in a batch)
23 LOCS7 Operation amount limiter function setting (All steps in a batch)
24 LOCS8 Setting time (All steps in a batch)
25 LOCS9 Run times
26 LOCSA End signal ON time
