Page 22

- 22 -
5.5
Common parameter setting mode SET 4 (1)
SET04
Name
Setting content
Initial value
1
SLH SV limiter upper limit (*2) (*3)
Thermocouple/RTD input (SLL + 5.0) to SV setting range upper limit (
C)
(SLL + 5) to SV setting range upper limit (
C)
1200
Current/voltage input (SLL + 50) to SV setting range upper limit (digit)
12000
2
SLL SV limiter lower limit (*2) (*3)
Thermocouple/RTD input SV setting range lower limit to (SLH - 5.0) (
C)
SV setting range lower limit to (SLH - 5) (
C)
0
Current/voltage input (SLH - 50) to SV setting range lower limit (digit)
3
CNT Control type setting
1 Primary...pid control
Secondary---None
1
2 Primary---onoff control
Secondary---None
3 Primary---pid control
Secondary---pid control
4 Primary---pid control
Secondary---onoff control
5 Primary---onoff control
Secondary---onoff control
4
DIR Forward/reverse operation setting
0 Reverse operation
0
1 Forward operation
5
MV1 Primary control operating amount
0.0 to 100.0 (%)
0.0
6
TUN Tuning type setting
1 Primary auto-tuning
1
2 Secondary auto-tuning
3 Primary/secondary auto-tuning
7
ATG AT coefficient setting
0.1 to 10.0 (times)
1.0
8
ATC AT sensitivity setting
Thermocouple/RTD input 0.0 to 999.9 (°C) 0 to 999 (°C)
2
Voltage/current input 0 to 9999 (digit)
9
AT1 AT startup screen for PID No. 1 (low
temperature)
Startup starts/stops by setting a SV and using the RUN/STOP key.
Characters and PV are alternately displayed in the PV digit during AT.
The SV range is SLL to PM1.
0
10
AT2 AT startup screen for PID No. 2
(intermediate temperature)
Startup starts/stops by setting a SV and using the RUN/STOP key.
Characters and PV are alternately displayed in the PV digit during AT.
The SV range is PM1 to PM2.
0
11
AT3 AT startup screen for PID No. 3 (high
temperature)
Startup starts/stops by setting a SV and using the RUN/STOP key.
Characters and PV are alternately displayed in the PV digit during AT.
The SV range is PM2 to SLH.
10
12
ATALL AT startup screen for PID No. 1~3
Use the RUN/STOP key for start and stop.
During the auto tuning, Character//PV is alternately displayed at PV
display, and No. 1 – 3/SV are alternately displayed at SV display.
13
P1 Proportional band setting for PID No. 1 (low temperature)
0.1 to 200.0 (%)
3.0
14
I1 Integral time setting for PID No. 1 (low temperature)
0 to 3600 (seconds)
0
15
D1 Derivative time setting for PID No. 1 (low temperature)
0 to 3600 (seconds)
0
16
PM1 Intermediate point 1 setting for the
PID range
Thermocouple/RTD input SLL to SLH- 5.0 (
C) SLL to SLH - 5 (
C)
0
Current/voltage input SLL to SLH - 50 (digit)
0
17
P2 Proportional band setting for PID No. 2 (intermediate
temperature)
0.1 to 200.0 (%)
3.0
18
I2 Integral time setting for PID No. 2 (intermediate temperature) 0 to 3600 (seconds)
0
19
D2 Derivative time setting for PID No. 2 (intermediate
temperature)
0 to 3600 (seconds)
0
20
PM2 Intermediate point 2 setting for the PID range
PM1 to SLH (
C)
10
21
P3 Proportional band setting for PID No. 3 (high temperature)
0.1 to 200.0 (%)
3.0
22
I3 Integral time setting for PID No. 3 (high temperature)
0 to 3600 (seconds)
0
23
D3 Derivative time setting for PID No. 3 (high temperature)
0 to 3600 (seconds)
0
24
T1 Primary control proportional cycle
0.1 to 120.0 (seconds)
1.0
25
ARW Anti-reset windup
0.0 to 110.0 (%) Function turned off at 110.0 (%) setting
110.0
26
PS1 Primary control loop abnormalityPV
variation setting
Thermocouple/RTD input 0.0 to 999.9 (
C) or 0 to 999 (
C)
0
Current/voltage input 0 to 9999 (digit)
27
LOP1 Primary control loop abnormality time
setting
0 to 3600 (seconds)
0
28
CMOD Primary control off-point position
selection setting
0 SV unit setting
0
1 Upper
2 Middle
3 Lower
29
C1 Primary control sensitivity control
Thermocouple/RTD input 0.0 to 999.9 (
C) 0 to 999 (
C)
1
Current/voltage input 0 to 9999 (digit)
10
30
CP1 Primary control off-point position
Thermocouple/RTD input -999.9 to 999.9 (
C) -999 to 999 (
C)
0
Current/voltage input -9999 to 9999 (digit)
