- 25 -
5.7 Common parameter setting mode SET 9 (2)
SET09 Name Setting content Initial value
With the selection of [MLF = 2,3], the following 18 to 41 are selectable.
18
CM1
CT1 current value monitor
0.0 to 50.0 (A) Displays the average at MLF=2.
Displays the R.M.S at MLF=3.
19 OH01 Operation amount limiter point 1
A point is defined as a location corresponding to the number resulted from
calculation of divided values of SLL to SLH into 10 equal segments
multiplied by the point No.
0.0 to 100.0 (%)
100.0
20 OH02 Operation amount limiter point 2
21 OH03 Operation amount limiter point 3
22 OH04 Operation amount limiter point 4
23 OH05 Operation amount limiter point 5
24 OH06 Operation amount limiter point 6
25 OH07 Operation amount limiter point 7
26 OH08 Operation amount limiter point 8
27 OH09 Operation amount limiter point 9
28 OH10 Operation amount limiter point 10
29 OH11 Operation amount limiter point 11
30 AH01 Current value limiter point 1
Upper current limit at the operation amount limiter point
0.0 to 30.0 (A)
30.0
31 AH02 Current value limiter point 2
32 AH03 Current value limiter point 3
33 AH04 Current value limiter point 4
34 AH05 Current value limiter point 5
35 AH06 Current value limiter point 6
36 AH07 Current value limiter point 7
37 AH08 Current value limiter point 8
38 AH09 Current value limiter point 9
39 AH10 Current value limiter point 10
40 AH11 Current value limiter point 11
41 AHC Current value limiter sensitivity 0.1 to 30.0 (A) 0.2
42 and 43 are always effective; 44 and 45 are selectable when [CNT = 3].
42 OU1 Primary control operation amount
increase rate
0.0 to 549.9 (%): 0.0% indicates the function turned off. 0.0
43 OUTM1 Primary control operation amount
increase time
0 to 3600 (second): 0 indicates no function. 0
44 OU2 Secondary control operation
amount increase rate
0.0 to 549.9 (%): 0.0% indicates the function turned off. 0.0
45 OUTM2 Secondary control operation
amount increase time
0 to 3600 (second): 0 indicates no function. 0
