Common parameter setting mode SET 4 (2)
SET04 Name Setting content Initial value
31 MV2 Secondary control operating amount 0.0 to 100.0 (%) 0.0
32 PC1 Secondary control proportional band setting for PID
No. 1 (low temperature)
0.10 to 10.00 (times) 1.00
33 PC2 Secondary control proportional band setting for PID
No. 2 (intermediate temperature)
0.10 to 10.00 (times) 1.00
34 PC3 Secondary control proportional band setting for PID
No. 3 (high temperature)
0.10 to 10.00 (times) 1.00
35 T2 Secondary control proportional cycle 0.1 to 120.0 (seconds) 1.0
36 PS2 Secondary control loop abnormality
PV variation setting
Thermocouple/RTD input 0.0 to 999.9 (

C) or 0 to 999 (

C)
0
Current/voltage input 0 to 9999 (digit)
37 LOP2 Secondary control loop abnormality time setting 0 to 3600 (seconds) 0
38 C2 Secondary control sensitivity setting
Thermocouple/RTD input 0.0 to 999.9 (

C) 0 to 999 (

C) 1
Current/voltage input 0 to 9999 (digit) 10
39 CP2 Secondary control off-point position
Thermocouple/RTD input -999.9 to 999.9 (

C) -999 to 999
(

C)
0
Current/voltage input -9999 to 9999 (digit)
40 PBB Manual reset
0.0 to 100.0 (%) when CNT = 1
-100.0 to 100.0 (%) when CNT = 3 and 4
0.0
41 DB Dead band
Thermocouple/RTD input -999.9 to 999.9 (

C) -999 to 999
(

C)
0
Current/voltage input -9999 to 9999 (digit)
42 O1F Target connection output 1 selection
Connection content selection
0 MV1
0 1 MV2
2 Transmission output
43 TRN1 Transmission output function setting
Transmission content selection
03
*1 PV (measurement value) output
*2 SV (setting value) output
*3 MV 1 (Primary Control Amt.) output
*4 MV 2 (Secondary Control Amt.) output
Forward/reverse operation selection
0* Forward operation
1* Reverse operation
44 TRH1 Transmission scaling upper limit setting TRL1~2999.9(℃) or TRL1~2999(℃) 1200
45 TRL1 Transmission scaling lower limit setting -1999.9～TRH1 (℃) or -1999～TRH1 (℃) 0
46 O2F Target connection output 1 selection
Connection content selection
0 MV1
1 1 MV2
2 Transmission output
47 TRN2 Transmission output function setting
Transmission content selection
04
*1 PV (measurement value) output
*2 SV (setting value) output
*3 MV1 (Primary Control Amt.) output
*4 MV2 (Secondary Control Amt.) output
Forward/reverse operation selection
0* Forward operation
1* Reverse operation
48 TRH2 Transmission scaling upper limit setting TRL2~2999.9(℃) or TRL2~2999(℃) 1200
49 TRL2 Transmission scaling lower limit setting -1999.9～TRH2 (℃) or -1999～TRH2 (℃) 0
