- 24 -
5.6 Common parameter setting mode SET 5 to 8
SET05 to SET08 Name Setting content Initial value
1 E*F1 Event function 1 setting
Function Add-on function
00
*0 None 0* None
*1 Deviation upper and lower limits 1* Hold
*2 Deviation upper limit 2* Standby
*3 Deviation lower limit 3* Delay
*4 Deviation range 4* Hold + standby
*5 Absolute value upper and lower limits 5* Hold + Delay
*6 Absolute value upper limit 6* Standby + Delay
*7 Absolute value lower limit 7* Hold + standby + Delay
*8 Absolute value range
2 E*H Event upper limit setting
Thermocouple/RTD input -1999.9 to 2999.9 (

C) -1999 to 2999 (

C) Note that for
R, B and PR40-20 of thermocouple, the following is to be applied. -1999 to 9999 (

C)
0
Current/voltage input -19999 to 29999 (digit)
3 E*L Event lower limit setting
Thermocouple/RTD input -1999.9 to 2999.9 (

C) -1999 to 2999 (

C) Note that for
R, B and PR40-20 of thermocouple, the following is to be applied. -1999 to 9999 (

C) 0
Current/voltage input -19999 to 29999 (digit)
4 E*C Event sensitivity setting
Thermocouple/RTD input 0.0 to 999.9 (

C) 0 to 999 (

C)
0
Current/voltage input 0 to 9999 (digit)
5 E*T Event Delay timer setting 0 to 9999 (second) 0
6 E*F2 Event function 2 setting
(loop abnormality)
Function Add-on function
00 *0 Nonexistent 0* None
*1 Existent 1* Hold
7 E*P Event polarity setting 0 Normal open 1 Normal close 0
5.7 Common parameter setting mode SET 9 (1)
SET09 Name Setting content Initial value
1 MLF
Operation amount function
setting 0 None 2 Operation amount current limiter(average)
0
1 Operation amount limiter 3 Operation amount current limiter(R.M.S)
With the selection of [MLF =1], the following 2 to 9 are selectable for [CNT =1]; the following 2 to 17 are selectable for [CNT = 3 or 4].
* Below, 2 and 3 are for the operation amount limiter function setting, i.e., effective when 1 is selected.
2 MLH11 Primary control operation amount limiter upper limit 1 MLL11 to 100.0(%) 100.0
3 MLL11 Primary control operation amount limiter lower limit 1 0.0 to MLH11(%) 0.0
* Below, 4 and 5 are for the operation amount limiter function setting, i.e., effective when 2 is selected.
4 MLH21 Primary control operation amount limiter upper limit 2 MLL21 to 100.0(%) 100.0
5 MLL21 Primary control operation amount limiter lower limit 2 0.0 to MLH21(%) 0.0
* Below, 6 and 7 are for the operation amount limiter function setting, i.e., effective when 3 is selected.
6 MLH31 Primary control operation amount limiter upper limit 3 MLL31 to 100.0(%) 100.0
7 MLL31 Primary control operation amount limiter lower limit 3 0.0 to MLH31(%) 0.0
* Below, 8 and 9 are for the operation amount limiter function setting, i.e., effective when 4 is selected.
8 MLH41 Primary control operation amount limiter upper limit 4 MLL41 to 100.0(%) 100.0
9 MLL41 Primary control operation amount limiter lower limit 4 0.0 to MLH41(%) 0.0
* Below, 10 and 11 are for the operation amount limiter function setting, i.e., effective when 1 is selected.
10 MLH12 Secondary control operation amount limiter upper limit 1 MLL12 to 100.0(%) 100.0
11 MLL12 Secondary control operation amount limiter lower limit 1 0.0 to MLH12(%) 0.0
* Below, 12 and 13 are for the operation amount limiter function setting, i.e., effective when 2 is selected.
12 MLH22 Secondary control operation amount limiter upper limit 2 MLL22 to 100.0(%) 100.0
13 MLL22 Secondary control operation amount limiter lower limit 2 0.0 to MLH22(%) 0.0
* Below, 14 and 15 are for the operation amount limiter function setting, i.e., effective when 3 is selected.
14 MLH32 Secondary control operation amount limiter upper limit 3 MLL32 to 100.0(%) 100.0
15 MLL32 Secondary control operation amount limiter lower limit 3 0.0～MLH32(%) 0.0
* Below, 16 and 17 are for the operation amount limiter function setting, i.e., effective when 4 is selected.
16 MLH42 Secondary control operation amount limiter upper limit 4 MLL42 to 100.0(%) 100.0
17 MLL42 Secondary control operation amount limiter lower limit 4 0.0 to MLH42(%) 0.0
