Sterlco Micro Series Water Temperature Control Unit User Manual
Page 9
MICRO Series Water Temperature Control Units
Page 9
Figure 1
Typical MICRO Series Water Temperature Control Unit and Specifications
Model
Dimensions
Shipping
number Pump
H W D
weight
460 / 230
hp
kW
gpm
lpm
psig
kPa
in.
cm
in.
cm in. cm lbs.
Kg
1/2
0.37
15 25
MICRO,
3 kW heater
3/4
0.56
20 30
17½ 44.0 9½ 24.0 23 58.0 110
50
Figure 2
MICRO Series Unit Full-Load Amps
Model
Full-load amps at 460 volts
hp
kW
3 kW heater
6 kW heater
9 kW heater
0.5 hp 0.37 kW
4.8 amps
8.5 amps 12.3
amps
0.75 hp 0.56 kW
5.2 amps
8.9 amps 12.7
amps
Coolin
Fr
Cool
To
