MICRO Series Water Temperature Control Units

Page 13

Chapter 3: Installation

3-1 Installation Location Considerations

MICRO Series systems are portable and can be installed almost anywhere. As
with all equipment installations, follow all applicable codes and regulations.

; The recommended ambient temperature range for MICRO Series

installations is from +14ºF (-10ºC) to a maximum operating ambient
temperature of 131

°F (55ºC). Recommended ambient storage temperature

range is from -13ºF to 149ºF
(-25ºC to 65ºC). If storing the unit below freezing temperatures, make sure
the unit has an anti-freeze mixture circulated inside.

; Provide a minimum of twelve inches (12” or about 30 cm) clearance on all

sides of the cabinet to allow circulation of cooling air.

; Locate the unit as close to the process as practical.

3-2 Process Approach Temperature Considerations

If the differential (U) between COOLING WATER IN and TO PROCESS
temperatures is less than 10

°F (7ºC), consult our Sales Department for advice on

how to control low approach applications.

3-3 External Piping Sizing Considerations

; All external hose and piping should be adequately sized to assure minimum

external pressure drop.

; Low external piping pressure drop is needed for best operation.

Note: Use a backup wrench to support MICRO Series system piping

when making process piping connections.

!

CAUTION

All external valves, fittings, and hoses must be rated at a minimum of

150 psig and 250

°F (1,034.25 kPa/10.34 bars and 121ºC).
