ROTRONIC HygroLab C1 - Manual (Page 9)

E-M-HyLabC1-V1
Rotronic AG
Bassersdorf, Switzerland
Document code Unit
HygroLab C1 bench-top indicator:
User Guide
Instruction Manual
Document Type
Page 9 of 28
Document title
© 2011; Rotronic AG E-M-HyLabC1-V1
Main Menu Menu Items
Submenu
Items Selections or
Information
Notes
Aw Settings Enable AW ON / OFF Enable = ON changes the
display as follows:
o
Humidity unit changes
to a
w
o No calculated
parameter
SaveResult ON / OFF ON: When the Aw
measurement is ended,
both the end result and
temperature are saved in
the following data bins:
Probe 1: to Bin 1
Probe 2: to Bin 2, etc.
Mode AwQuick / AwE o AwQuick: accelerated
water activity
measurement
o AwE: conventional
water activity
measurement
Dwell Time minutes Dwell time (AwQuick)
AwQ Temp °C / minute Temperature stability
definition (AwQuick)
AwE Temp °C / minute Temperature stability
definition (AwE)
AwE Humi a
w
/ minute Humidity stability definition
(AwE)
Data Storage o Displays the names of
the 4 data bins
Bin 1 = Probe 1
Bin 2 = Probe 2, etc.
o Press on ENTER to
select the highlighted
data bin
View Samples
o Shows the individual
data records
o Use the up and down
keys to navigate the
records
Summary
Shows the minimum,
maximum and average
values for the data bin
Clear Data Clears the data bin
