6 Maintenance
6.1 Periodic calibration check of the HygroClip 2 probe
Both the Pt 100 RTD temperature sensor used in the probe and associated electronics are very stable and
should not require any calibration after the initial factory adjustment. Long term stability of the ROTRONIC
Hygromer humidity sensor is typically better than 1 %RH per year. For maximum accuracy, calibration of the
probe should be verified every 6 to 12 months. Applications where the probe is exposed to significant pollution
may require more frequent verifications.
6.2 Cleaning or replacing the probe dust filter
See document E-M-HC2 Probes-V1
6.3 Firmware updates
Firmware updates will be available on the ROTRONIC website for downloading. Firmware files are given a
name that shows both to which device the file applies and the version number of the firmware. All firmware
files have the extension HEX.
WARNING
: for reasons of compatibility update the current instrument Firmware only with a Firmware file with
the same “Main” version. Examples: 1.0a  1.5b = OK, 1.3b  2.1d = NOT OK
Procedure for updating the firmware:
o Connect the HygroLab C1 to a USB port of a PC with the ROTRONIC HW4 software installed. Note
that the ROTRONIC USB driver must be installed on the PC as explained in the HW4 manual E-M-
HW4v3-Main
Note: the Ethernet port can be also used to connect the HygroLab C1 to the HW4 PC.
.
o Copy the firmware update file from the ROTRONIC website to the PC.
o Start HW4 software on the PC and search for the HygroLab C1 (HW4 Main Menu Bar > Devices and
Groups > Search for USB Masters).
o After finding the HygroLab C1, expand the device tree to its functions. Select Device Manager. In the
Device Manager menu bar select Tools > Firmware Update.
For instructions see document E-M-HW4v3-F2-019
