Dwyer Mark - Manual (Page 6)

5
Construction
Output
Type
Switch Type
& Rating
1
3
4
1
2
3
31
32
35
310
320
4
5
51
52
6
7
8
9
A
B
C
D
G
H
I
M
0
R
S
T
V
W
Mark 1, Magnetic Coupling
Mark 3, Multi-Turn
Mark 4, Thru-Shaft
1 Switch
2 Switches
1K OHM Potentiometer 1/2%. Available with switches, see note below.*
1K OHM Potentiometer 1/4%. Available with switches, see note below.*
2K OHM Potentiometer. Available with switches, see note below.*
5K OHM Potentiometer. Available with switches, see note below.*
10K OHM Potentiometer. Available with switches, see note below.*
20K OHM Potentiometer. Available with switches, see note below.*
4 Switches
Transmitter 1K OHM Potentiometer 1/2%. 4 to 20mA. Available with
switches, see note below.*
Transmitter 1K OHM Potentiometer 1/4%. Available with switches, see note
below.*
Transmitter 2K OHM Potentiometer. Available with switches, see note
below.*
6 Switches. Available with Switch Types B, C, I, R, V, W.
AS-interface and 1 Switch. Available with Switch Types B, I, R, W.
AS-interface and 2 Switches. Available with Switch Types B, I, R, W.
Transmitter with HART
® communication. Available with switches, see note
below.*
SPDT Snap, Rated: 15A @ 125/250/480 VAC (~) ; 1/8 hp @ 125 VAC
(~), 1/4 hp @ 250 VAC (~), 1/2A @ 125 VDC ( ), 1/4A @ 250 VDC( ).
Inductive Sensor. 10 to 30 VDC ( ). Load: 0.1A.
SPDT High Temperature Snap, 350°F (176°C) for 600 hours, Rated:
15.1A @ 125/250/277 VAC (~).
DPDT Snap, Rated: 10A @ 125/250 VAC (~), 0.3A @ 125 VDC ( ),
0.15A @ 250 VDC ( ).
SPDT Gold Contact Snap, Rated: 1A @ 125 VAC (~).
SPDT Hermetically Sealed Snap, Rated: 1A @ 125 VAC (~).
NAMUR Inductive Sensor. 15 mA max @ 5-25 VDC ( ).
SPDT Magnetic Blow-Out, Rated: 10A @ 125 VAC (~)/VDC ( ), 1/4 hp
@ 125 VAC (~)/VDC ( ).
No Switches
SPDT Hermetically Sealed Reed, Rated: 2A @ 125 VAC (~), 2A @
24 VDC ( ).
SPDT Snap, Rated: 4A @ 125/250 VAC (~).
SPDT High Temperature Snap, 250°F (121°C) Continuous, Rated: 5A
@ 125/250/480 VAC (~).
SPDT Snap, Rated: 10A @ 125/250 VAC (~), 1/3 hp @ 125/250 VAC
(~), 1/2A @ 125 VDC ( ), 1/4A @ 250 VDC ( ), 4A @ 125 VAC
(tungsten).
SPDT Gold Contact Snap, Rated 0.1A @ 125 VAC (~).
Available
Options “A”
signifies
available with
corresponding
construction
style.
Mark
1 3 4
--
A
A
A
A
A
A
A
A
A
A
A
--
--
A
A
--
A
A
A
--
--
A
A
--
--
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
*Note: Mark 1 and 4 potentiometer and transmitter outputs will have no switches when ordered with switch type 0; 2
switches if ordered with switch types B, C, I, R, V, or W; and 4 switches if ordered with switch type S. Mark 3
potentiometer and transmitter outputs will have no switches when ordered with switch type 0, and 2 switches if ordered
with switch types A, D, G, M or T.
Available on Mark 1, 3, 4
