Dwyer Mark - Manual (Page 26)

25
SEE WIRING
SCHEMATIC
SEE WIRING
SCHEMATIC
WIRING SCHEMATIC
BY OTHERS
I.S. BARRIER
I.S. BARRIER
12 VDC
OR
24 VDC
SW 4
TOP
SWITCH
SW 3
ABOVE 2nd
SWITCH
SW 2
ABOVE 1st
SWITCH
SW 1
BOTTOM
SWITCH
C
BRN
C
WHT
C
BLK
C
RED NO
BRN
NO
WHT
NO
BLK
NO
RED NC
BRN
NC
WHT
NC
BLK
NC
RED
7 8 9 10 11 12
1 2 3 4 5 6
Figure 13: Intrinsically Safe Wiring for transmitter with HART ® communication output. Refer to proper switch figure if
unit has switches as well.
Figure 12: Intrinsically Safe wiring for transmitter output. Refer to proper switch figure if unit has switches as well.
WIRING SCHEMATIC
I.S. BARRIER
I.S. BARRIER
BY OTHERS
12 VDC
OR
24 VDC
TERMINAL 2
SEE WIRING
SCHEMATIC
TERMINAL 1
SEE WIRING
SCHEMATIC
