5. The following chart shows the various combinations of screw positions and resulting revolutions between switch
actuation.
6. Switch actuation at all intermediate number of revolutions or partial revolutions can be selected by turning the cam
screws in or out when located at the nearest location shown above. Any partial number of turns may be selected,
such as 4-1/2 or 12-3/4.
See Pages 19-25 for wiring procedure, intrinsic safety parameters, relevant warnings and schematics.
Cam Screw Locations
Number of Revolutions
Switch #1
Switch #2
Between Switch Actuation
E
A
1
D
D
4
C
A
7
B
A
10
A
A
13
A
B
16
A
C
19
A
D
22
A
E
25
