4
Browsing menus and device configuration
To browse menus press the “Menu”
○
button which
allows to switch from one menu to another, whereas the
“Battery” ● button provides access to sub-menus.
To exit the menu, press the “Battery” ● button over
“Exit”: exiting will always return you to the measurement
screen, whatever the menu level you were in.
Press the ON/OFF ● button to exit, to return to the
previous menu or measurement mode.
○
“Menu”
● “Battery”
● “ON/OFF”
The menu is structured as illustrated below.
MENU
UNIT
UNIT
> l/h
- l/min
- GPM
EXIT
MENU
LIQUID
LIQUID
> Water
- 30% glycol
- 50% glycol
EXIT
MENU
VERSION
CALEFFI S.p.A.
I° 001
SW 0/10 HW 0/10
Reset
EXIT
When browsing menus, inactive headings are shown
with a “minus” sign (“-”) whilst active headings have a
“greater than” sign (“>”). Take the following unit of
measurement for instance, i.e. “l/min”:
UNIT OF MEASUREMENT
“Battery” - l/h
“Menu” > l/min
“Menu” - GPM
IMPORTANT
: if a configuration parameter is modified during a
measurement, wait a few seconds for the reading to be corrected.
MENU
UNIT
○
MENU
LIQUID
○
MENU
VERSION
○
MEASUREMENT
MODE
UNIT
> l/h
○
UNIT
- l/min
○
UNIT
- GPM
○
UNIT
EXIT
○
LIQUID
> Water
○
LIQUID
- G30%
○
LIQUID
- G50%
○
LIQUID
EXIT
CALEFFI S.p.A.
I° 001
○
CALEFFI S.p.A.
SW 0/10 HW 0/10
○
CALEFFI S.p.A.
Reset
○
CALEFFI S.p.A.
EXIT
Battery charge
A battery charger with the following specifications is used to charge the internal battery:
- Electric supply voltage: 18 V (dc)
- Maximum current absorbed by the device when charging (@18 V): 50 mA
- Average current absorbed by the device when charging (@18 V): 20 mA
- Maximum output of power unit: 6 W
- Connection: audio jack 3.5 mm
- Battery: rechargeable NiMh 9 V 225 mAh
The battery charge is expressed as a % from 100% to 0%: when the battery charge is too low the device should be charged up.
The flow meter also functions effectively when charging, hence it can even be used when connected to the battery charger.
Pressing the “Battery” button displays the “BATTERY CHARGE”.
● Measurement
mode
● Measurement
mode
● Measurement
mode
● Measurement
mode
● Measurement
mode
● Measurement
mode
● Measurement
mode
● Measurement
mode
● Measurement
mode
● Measurement
mode
● Measurement
mode
● Measurement
mode
●
●
●
