0 - 5 vdc, 28 vdc power supply, Pulse output – Badger Meter Vortex Meters User Manual
Page 13: Digital display, Counter
Form No. 09-VRX-UM-00007
11
Figure 10 and figure 11 show typical connections for the 0-5 VDC and pulse output options.
0 - 5 VDC OUTPUT
FIGURE 10
Output
8 to 28 VDC
Output
Ground
+8-28 VDC
Gnd
0 - 5 VDC
Digital Display
Programming
8-28 VDC
POWER
SUPPLY
PULSE OUTPUT
+8-28 VDC
Gnd
Output
8 to
Outp
Grou
8-28 VDC
POWER
SUPPLY
Counter
Pulse
Output
FIGURE 11
