CALIBRATION
Testers are calibrated with a 32 cSt (150 SUS) hydraulic oil . Standard calibration is done using 5 points and is traceable to NIST,
ISO 9001 . An optional 10 point calibration can be performed for increased accuracy .
SERIES/MODEL NUMBER DESIGNATIONS
Series Model Number *
Nominal Port
Size
Flow Rate Power HP (kW)
PFM6-15 F5080 (CE) - XXX SAE 12 1…15 GPM
N/A
PFM6-30 F5079 (CE) - XXX SAE 12 2…30 GPM
PFM6-60 F5078 (CE) - XXX SAE 16 3…60 GPM
PFM6-85 F5077 (CE) - XXX SAE 16 4…85 GPM
PFM6-200 F5076 (CE) - XXX SAE 24 7…199 .9 GPM
PFM6-15 F5110 (CE) - XXX G 3/4 4…56 LPM
N/A
PFM6-30 F5111 (CE) - XXX G 3/4 7 .5…113 .6 LPM
PFM6-60 F5112 (CE) - XXX G 1 12…227 LPM
PFM6-85 F5113 (CE) - XXX G 1 15…321 LPM
PFM6-200 F5114 (CE) - XXX G 1-1/2 26…757 LPM
PFM6BD-60 F5082 (CE) - XXX SAE 16 3…60 GPM / 12…227 LPM
N/A PFM6BD-85 F5083 (CE) - XXX SAE 16 4…85 GPM / 15…321 LPM
PFM6BD-200 F5084 (CE) - XXX SAE 24 7…199 .9 GPM / 26…757 LPM
PFM8-15 F5061 SAE 12 1…15 GPM / 4…56 LPM 52 .5 (39)
PFM8-30 F5058 SAE 12 2…30 GPM / 7 .5…113 .6 LPM 105 (78)
PFM8-60 F5052 SAE 16 3…60 GPM / 12…227 LPM 210 (157)
PFM8-85 F5053 SAE 16 4…85 GPM / 15…321 LPM 98 (222)
PFM8-200 F5054 SAE 24 7…199 .9 GPM / 26…757 LPM 700 (522)
* Replace XXX with Psi, BAR, KG/CM2 or MPA to specify complete model number .
Table 1: Model number designations
READ INSTRUCTIONS THOROUGHLY BEFORE INSTALLING THE TESTER. IF YOU HAVE ANY QUESTIONS REGARDING
PRODUCT INSTALLATION OR MAINTENANCE, CALL YOUR LOCAL SUPPLIER OR THE FACTORY FOR MORE INFORMATION.
