SPECIFICATIONS
Material
Housing 6013-T351 Anodized aluminum
Turbine Rotor T416 Stainless steel
Rotor Supports 6061-T6 Aluminum
Seals
Buna N standard
Viton® and EPR optional
Ball Bearings 440 C Stainless steel
Hub Cones 6061-T6 Aluminum alloy
Temperature Probe 12L14 Steel, electroless nickel plate
PFM6/8 Series Testers
Valve
Cold rolled steel body with 303 SS stem (for 15/30 Models)
12L14 steel body with 303 SS stem (for 60/85/200 Models)
Sleeve for 200 Model D .O .M . steel tube
Poppet 12L14 steel, hardened
Straightening Sections
CA360 Brass (for 15/30 Models)
6061-T6 Aluminum (for 60/85/200 Models)
Cones 2024-T4 Aluminum
PFM6BD Series Testers
Valve 12L14 steel body with 303 SS stem
Sleeve for 200 Model 4340 Alloy steel, hardened
Poppet 6061-T6 Aluminum
Straightening Sections 2024-T4 Aluminum
Cones
SAE Straight thread O-ring boss, female, J1926/1;
BSPP ISO1179
Magnetic Pick-Up
Body 12L14 steel, electroless nickel plate
Nut 12L14 steel, electroless nickel plate
Electronic Case Cover Cold rolled steel, zinc plate with clear seal, epoxy black paint
Performance
Flow Accuracy ±1% of full scale
Repeatability ±0 .2%
Pressure Rating 6000 Psi (414 Bar) maximum with a 3:1 safety factor
Turbine Response ≤200 ms
Fluid Temperature –4…300 °F (–20…150 °C)
Ambient Temperature –4…131 °F (–20…55 °C)
Flow Readout Linearity and zero shift = ±1 digit
Operating Pressure Up to 6000 psi (414 Bar, 41 .4 MPa, 420 kg/cm 2 )
Pressure Drop See “ΔP Captured Using Loading Valves” on page 16
Fluid Temperature Up to 300 °F (150 °C)
Readout Accuracy ±1 digit
Battery Type AA size alkaline, ~50 hr of service
Specifications
