Ecl 020 h, Standard - cooling mode, With pump – Airedale EcoChill 6kW - 46kW User Manual
Page 30: With buffer tank and pump, Cooling mode
30
EcoChill Installation Manual 7481930_v1.6.0_08_2013
ECL-ECLH 020-202
EN
10. OUTPUTS AND CAPACITIES DIFFERENT THAN NOMINAL FOR HEAT PUMP UNITS
10.1. ECL 020 H
version
STANDARD - COOLING MODE
(230V/1/50Hz - 400V/3/N/50Hz)
10.2. ECL 020 H
WITH PUMP
version
P
-
WITH BUFFER TANK AND PUMP
version
A
COOLING MODE
(230V/1/50Hz - 400V/3/N/50Hz)
TWP
EXTERNAL AIR TEMPERATURE (°C)
FROM -10°C TO 20°C
25
30
35
40
45
46
GL
YC
OL
%
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
4
10
6,35 1,35 4,71 5,99 1,52 3,93 5,63 1,70 3,31 5,27 1,86 2,83 4,90 2,01 2,44 4,54 2,11 2,15 4,47 2,12 2,11
6
0
6,68 1,36 4,93 6,31 1,53 4,12 5,93 1,71 3,46 5,54 1,88 2,95 5,16 2,03 2,55 4,79 2,13 2,25 4,71 2,15 2,20
7
0
6,81 1,36 5,00 6,43 1,54 4,18 6,04 1,72 3,51 5,64 1,90 2,97 5,27 2,04 2,59 4,89 2,14 2,28 4,81 2,16 2,23
8
0
6,94 1,39 5,00 6,55 1,56 4,19 6,16 1,74 3,54 5,76 1,90 3,03 5,37 2,04 2,63 4,98 2,15 2,32 4,91 2,16 2,27
10
0
7,18 1,41 5,10 6,79 1,58 4,29 6,38 1,76 3,63 5,98 1,92 3,11 5,57 2,06 2,71 5,18 2,16 2,40
-
-
-
12
0
7,43 1,43 5,21 7,02 1,60 4,38 6,60 1,78 3,72 6,19 1,94 3,19 5,78 2,07 2,78
-
-
-
-
-
-
14
0
7,67 1,44 5,31 7,25 1,62 4,48 6,82 1,79 3,80 6,40 1,95 3,27 5,98 2,09 2,86
-
-
-
-
-
-
16
0
7,91 1,46 5,41 7,47 1,64 4,57 7,04 1,81 3,89 6,60 1,97 3,35 6,17 2,10 2,94
-
-
-
-
-
-
18
0
8,14 1,48 5,50 7,70 1,66 4,64 7,25 1,83 3,96 6,81 1,99 3,42 6,37 2,12 3,01
-
-
-
-
-
-
TWP
EXTERNAL AIR TEMPERATURE (°C)
FROM -10°C TO 20°C
25
30
35
40
45
46
GL
YC
OL
%
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
Pc
(kW)
Pe
(kW)
EER
4
10
6,44 1,34 4,80 6,08 1,53 3,98 5,70 1,71 3,33 5,33 1,88 2,83 4,96 2,03 2,44 4,59 2,14 2,14 4,51 2,16 2,09
6
0
6,77 1,35 5,01 6,39 1,54 4,16 6,00 1,72 3,48 5,61 1,90 2,95 5,22 2,06 2,54 4,83 2,17 2,23 4,76 2,19 2,18
7
0
6,90 1,35 5,10 6,51 1,54 4,23 6,12 1,73 3,54 5,71 1,92 2,98 5,32 2,06 2,58 4,93 2,18 2,26 4,86 2,20 2,21
8
0
7,03 1,38 5,11 6,64 1,56 4,26 6,23 1,74 3,58 5,83 1,92 3,04 5,43 2,07 2,63 5,04 2,18 2,31 4,96 2,20 2,25
10
0
7,29 1,39 5,23 6,88 1,58 4,37 6,46 1,76 3,67 6,05 1,93 3,13 5,64 2,08 2,71 5,23 2,19 2,39
-
-
-
12
0
7,54 1,41 5,36 7,12 1,59 4,48 6,69 1,77 3,77 6,27 1,95 3,22 5,84 2,09 2,80
-
-
-
-
-
-
14
0
7,78 1,42 5,49 7,35 1,60 4,59 6,92 1,79 3,87 6,48 1,96 3,31 6,05 2,10 2,88
-
-
-
-
-
-
16
0
8,03 1,43 5,62 7,58 1,61 4,70 7,14 1,80 3,97 6,69 1,97 3,40 6,25 2,11 2,96
-
-
-
-
-
-
18
0
8,27 1,44 5,72 7,81 1,63 4,79 7,36 1,81 4,05 6,90 1,98 3,49 6,46 2,12 3,04
-
-
-
-
-
-
WARNING
Outputs calculated with % glycol shown in table. For temperatures and %
glycol different than shown refer to Magellano
SELECTION NOT POSSIBLE:
- Outside of operating limits
LEGEND
FUNCTION
Pc
Cooling capacity in kW
Pe
Power input in kW
Operation with glycol and DCPX acessory
Operation with glycol only
Operation with DCPX accessory
TWP
Temperature of Water Produced °C
Data to UNI EN14511: 2011
ΔT WATER DIFFERENT TO NOMINAL (ΔT 5°C)
3
5
8
10
Cooling capacity correction factors
0,99
1
1,02
1,03
Input power correction factors
0,99
1
1,01
1,02
FOULING FACTORS
[K*m2]/[W] 0,00005
0,0001
0,0002
Cooling capacity correction factors
1
0,98
0,94
Input power correction factors
1
0,98
0,95
