Airedale EcoChill 6kW - 46kW - Manual (Page 16)

16 EcoChill Installation Manual 7481930_v1.6.0_08_2013
ECL-ECLH 020-202
EN
Cooling only model ECL 020 025 030 040 050 070 080 090 102 152 202
SCROLL COMPRESSORS
Quantity /circuits
n°/n° 1/1 1/1 1/1 1/1 1/1 1/1 1/1 1/1 2/1 2/1 2/1
Compressor crankcase heaters n°/kW 1x70 1x70 1x70 1x70 1x35 1x35 1x35 1x65 2X35 2X35 2X65
Capacity control % 0-100 0-100 0-100 0-100 0-100 0-100 0-100 0-100 0-50-100 0-50-100 0-50-100
HEAT EXCHANGER SYSTEM SIDE
Quantity
n ° 1 1 1 1 1 1 1 1 1 1 1
Water content dm 3
Hydraulic connections IN|OUT Ø 1"¼ 1"¼ 1"¼ 1"¼ 1"¼ 1"¼ 1"¼ 1"¼ 1"¼ 1"¼ 1"¼
PROTECTIVE RATING
IP
24
HYDRONIC MODULE SYSTEM SIDE
BUFFER TANK
Volume
l 25 25 35 35 75 75 75 75 100 100 100
Heater quantity / electrical input n°/W ACCESSORY
EXPANSION TANK
Quantity/ volume
n°/l 2 2 2 2 5 5 5 5 8 8 8
Pressure setting bar 1,5 1,5 1,5 1,5 1,5 1,5 1,5 1,5 1,5 1,5 1,5
SAFETY VALVE
Quantity / pressure relief rating
n°/bar 1/6 1/6 1/6 1/6 1/6 1/6 1/6 1/6 1/6 1/6 1/6
DESUPERHEATER
Quantity
n ° - - - - 1 1 1 1 1 1 1
Water content dm 3 - - - -
Hydraulic connections IN|OUT Ø - - - - 1" 1" 1" 1" 1" 1" 1"
STANDARD AXIAL FANS
Quantity
n° 1 1 1 1 2 2 2 2 2 2 2
Air flow cooling mode m 3 /h 2500 2500 3500 3500 7200 7200 7300 7200 14000 13500 13500
Current input cooling mode A 0,085 0,085 0,14 0,14 0,28 0,28 0,28 0,28 0,74 0,74 0,74
Power input cooling mode kW 0,45 0,45 0,66 0,66 1,32 1,32 1,32 1,32 3,2 3,2 3,2
SOUND DATA
Sound pressure
dB(A) 30 30 37 37 38 38 38 37 44 45 46
Sound power dB(A) 61 61 68 68 69 69 69 68 76 77 78
CHARGE (The data provided can be amended at any time by AIREDALE if deemed necessary)
Refrigerant R410A
°
° kg 1.25 1.30 1.56 2.00 3.48 3.79 3.73 4.70
5.9 5.9 5.9 P kg 1.25 1.30 1.50 2.00 3.48 3.79 3.73 4.70
A kg 1.30 1.30 1.56 2.00 3.41 3.74 3.73 4.70
H
° kg 1.50 1.50 1.80 1.99 4.15 4.10 4.14 5.08
12.7 16.0 17.0 P kg 1.50 1.50 1.80 1.99 4.15 4.10 4.14 5.08
A kg 1.50 1.50 1.80 1.99 4.15 4.15 4.14 5.08
Oil
kg
A tipo
DIMENSIONS - WEIGHTS
Height
°|P mm 868 868 1000 1000 1252 1252 1252 1252
1450 1450 1450 A mm 868 868 1015 1015 1281 1281 1281 1281
Q mm - - - - 1281 1281 1281 1281
Width
°|P mm 900 900 900 900 1124 1124 1124 1124
750 750 750 A mm 1124 1124 1124 1124 1165 1165 1165 1165
Q mm - - - - 1165 1165 1165 1165
Depth
(without feet/with feet)
°|P mm 310/354 310/354 310/354 310/354 384/428 384/428 384/428 384/428
1750 1750 1750 A mm 384/428 384/428 384/428 384/428 550 550 550 550
Q mm - - - - 550 550 550 550
Weight
° kg 75 75 86 86 120 120 120 156 270 293 329
P kg 77 77 91 91 127 127 163 163 288 314 350
A kg 99 99 103 103 147 147 147 183
338 364 400
Q kg - - - - 151 151 187 187
Sound power
AIREDALE determines the value of sound power on the basis
of measurements made in accordance with ISO 9614-2, as
required for Eurovent certification. Sound pressure
Sound pressure in free field conditions over a reflective plane
(directivity factor Q=2), at 10 m distance from the external
surface of the unit, in accordance with ISO 3744.
