VT ANTI-VIBRATION MOUNTS
Set of anti-vibration mounts.
MODU-485A 4
Interface RS-485 for supervisory systems with MODBUS
protocol.
DCPX 4
Fan speed controller which allows correct operation
in cooling mode between external air temperatures of
+20°C and -10°C, in heat pump mode, in the summer
for production of domestic hot water, up to +42°C
(refer to the operating limits diagram).
In versions with desuperheater fitted as standard.
DRE 5
Electronic soft starter (reduces approximately 30%
in single circuits, 26% in dual circuits, 22% in three
circuits).
RA 7
Buffer tank electric heater (in versions A|Q). Provides
freeze protection of the buffer tank in winter off
periods.
KR 6 7
Evaporator electric heater
Plate heat exchanger electric heater. Provides freeze
protection of the evaporator in winter off periods.
AERWEB300
Allows the remote control of a chiller using a normal
PC connected via ethernet through a normal browser.
Available in 4 models:
AERWEB300-6: Web server for monitor and control of
a maximum of 6 units on a network RS485;
AERWEB300-18: Web server for monitor and control of
a maximum of 18 units on a network RS485;
AERWEB300-6G: Web server for monitor and control
of a maximum of 6 units on a network RS485 with
modem GPRS integrated;
AERWEB300-18G: Web server for monitor and control
of a maximum of 18 units on a network RS485 with
modem GPRS integrated.
BDX
Condensate drain pan.
KR B3 7
Base electric heater kit: avoids ice forming in the base.
MULTICONTROL
Allows the simultaneous control of multiple chillers
or heat pump units (up to 4) installed in a common
system, fitted with our MODU-CONTROL controller.
For a more complete function the following accessories
are available:
SPLW
System water sensor. In most cases the use of the sen-
sors supplied loose with each chiller/heat pump unit is
sufficient. In the case of common flow / return header
installation this sensor can be used to control the com-
mon water temperature of the chillers connected to
the header or just for reading values.
SDHW
Domestic hot water sensor. To be used with a storage
tank for the control of water temperature produced.
VMF-ACS
Electrical panel for enabling / complete control of a
domestic hot water tank:
1.
3 way valve control
2.
Anti-legionella
3.
Temperature sensor
4.
Immersion heater of:
3 kW single |three phase
6 kW three phase
8 kW three phase
VMF-E5B|N
Recess mounted panel or white or black colour with
back-lit LCD graphical display and capacitive keypad.
Allows enabling/centralised control of:
1.
A complete hydronic system comprising 1 master
and maximum of 5 slave fan coil units
2.
ChillerPump (INTERFACE RS 485 FROM MODU-
485A REQUIRED ACCESSORY)
3.
Circulating pumps: maximum configuration of 12
zone circulators
4.
Boiler: control of boiler enable for the produc-
tion of hot water
5.
Heat recovery units: maximum of 3 enables for
heat recovery units programmable by time-clock
and/or air quality sensor VMF-VOC, domestic hot
water module
6.
Complete control of domestic hot water produc-
tion (ACCESSORY VMF-ACS see above).
ECL
020
ECL
025
ECL
030
ECL
040
ECL
050
ECL
070
ECL
080
ECL
090
ECL
102
ECL
152
ECL
202
PR3
(°) - H - C
•
•
•
•
•
•
•
•
•
•
•
MODU-485A
4
ALL
•
•
•
•
•
•
•
•
•
•
•
AERWEB300-6
ALL
•
•
•
•
•
•
•
•
•
•
•
AERWEB300-18
ALL
•
•
•
•
•
•
•
•
•
•
•
AERWEB300-6G
ALL
•
•
•
•
•
•
•
•
•
•
•
AERWEB300-18G
ALL
•
•
•
•
•
•
•
•
•
•
•
DRE
5
(°) - H - C
-
-
-
-
5
5
5
5
5x2 5x2 5X2
MULTICONTROL
ALL
•
•
•
•
•
•
•
•
•
•
•
SPLW
•
•
•
•
•
•
•
•
•
•
•
SDHW
•
•
•
•
•
•
•
•
•
•
•
DCPX
4
(°) - C
50
50
50
50
50
50
50
50
52
52
52
H
51
51
51
51
51
51
51
51
53
53
53
VT
(°) - H - HP - C
9
9
9
9
9
9
9
9
15
15
15
A
9
9
9
9
15
15
15
15
15
15
15
RA
A
•
•
•
•
•
•
•
•
•
•
•
BDX
(°) / P
5
5
5
5
5
5
5
5
-
-
-
A
5
5
5
5
6
6
6
6
-
-
-
KR
6
(°) / P
2
2
2
2
2
2
2
2
2
2
2
A
-
-
-
-
2
2
2
2
2
2
2
KRB
7
-
-
-
-
-
-
-
-
3
3
3
VMF-E5B|N
4
ALL
•
•
•
•
•
•
•
•
•
•
•
VMF-ACS3KM
4
230V/1
•
•
•
•
VMF-ACS3KTN
4
400V/3N
•
•
•
•
•
•
•
•
•
•
•
VMF-ACS6KTN
4
400V/3N
•
•
•
•
•
•
•
•
•
•
•
VMF-ACS8KTN
4
400V/3N
•
•
•
•
•
•
•
•
•
•
•
4 Accessories MODU-485A |DCPX are required
for the control and production of DHW.
5 Only available with power supply 400V/3N
Factory fitted only.
6 Accessory not available for versions ECL
020…040°A | HA.
7 Factory fitted only.
x2 Indicates the quantity to order.
