EcoChill Installation Manual 7481930_v1.6.0_08_2013
ECL-ECLH 020-202
EN
Condensing unit model ECL C
020C
025C
030C
040C
050C
070C
080C
090C
102C
152C
202C
Cooling capacity
kW
5,7
6
7,5
9,6
13,7
16,8
20,8
22,5
26,9
33,4
43,7
Power input
°
kW
1,85
2,05
2,5
3,3
4,1
5
6,5
6,8
8,0
10,2
13,5
EFFICIENCIES
EER
°
W/W
3,08
2,93
3,00
2,91
3,34
3,36
3,20
3,31
3,36
3,27
3,24
UNIT PROTECTIVE RATING
IP
24
24
24
24
24
24
24
24
24
24
24
ELECTRICAL DATA
Total current input
230V/1
A
9,50
10,00
13,00
16,30
-
-
-
-
-
-
-
400V/3N
A
3,70
4,20
4,70
6,30
8,90
9,90
12,40
13,10
15,6
18,8
24,7
Maximum current (FLA)
230V/1
A
16,5
16,5
19,7
23,7
-
-
-
-
-
-
-
400V/3N
A
6
6
6,7
8,7
11,3
13,5
16,3
17,3
22
26
32
Starting current (LRA)
230V/1
A
59,5
62,5
83,7
98,7
-
-
-
-
-
-
-
400V/3N
A
26,5
32,5
35,7
48,7
65,3
75,3
102,3
96,3
76
87
117
SCROLL COMPRESSORS
Quantity /circuits
n°/n°
1/1
1/1
1/1
1/1
1/1
1/1
1/1
1/1
2/1
2/1
2/1
Compressor crankcase heaters
n°/kW
1x70
1x70
1x70
1x70
1x35
1x35
1x35
1x65
2X35
2X35
2X65
Capacity control
%
0-100
0-100
0-100
0-100
0-100
0-100
0-100
0-100 0-50-100 0-50-100 0-50-100
STANDARD AXIAL FANS
Quantity
n°
1
1
1
1
2
2
2
2
2
2
2
Air flow cooling mode
m
3
/h
2500
2500
3500
3500
7200
7200
7300
7200
14000
13500
13500
Current input cooling mode
A
0,085
0,085
0,14
0,14
0,28
0,28
0,28
0,28
3,2
3,2
3,2
Power input cooling mode
kW
0,45
0,45
0,66
0,66
1,32
1,32
1,32
1,32
0,74
0,74
0,74
CHARGE (The data provided can be amended at any time by AIREDALE if deemed necessary)
Refrigerant R410A
kg
1,25
1,30
1,56
2,00
3,48
3,79
3,73
4,70
Oil
kg
REFRIGERANT CONNECTIONS
Gas line
Ø
15,88
15,88
15,88
15,88
22
22
22
28
28
28
28
Liquid line
Ø
9,52
9,52
12,7
12,7
15,88
15,88
15,88
15,88
15,88
15,88
15,88
DIMENSIONS - WEIGHTS
Height
mm
868
868
1000
1000
1252
1252
1252
1252
1450
1450
1450
Width
mm
900
900
900
900
1124
1124
1124
1124
750
750
750
Depth
(without feet/with feet)
mm 310/354 310/354 310/354 310/354 384/428 384/428 384/428 384/428
1750
1750
1750
Weight
kg
70
70
78
78
110
110
141
141
COOLING
Evaporating temperature
5°C
External air temperature
35 °C
Sound power
AIREDALE determines the value of sound power on the basis
of measurements made in accordance with ISO 9614-2, as
required for Eurovent certification.
Sound pressure
Sound pressure in free field conditions over a reflective plane
(directivity factor Q=2), at 10 m distance from the external
surface of the unit, in accordance with ISO 3744.
