6.3
Message structure in function block protocol
6.3.1
INSTRUMENT
Message structure for function ‘General’
Block access to configuration data
max. eff. length: 41 bytes
STX B3 , 0 , 0 = 0 , 0 , 5 , C900 , Adr1 , C904 , C902 , Adr2
ETX
BCC
Message structure for function ‘I/O connection’
Block access to configuration data
max. eff. length: 43 bytes
STX B3 , 0 , 2 = 0 , 1 , HC100 , 4 , C500 , C530 , C551 , HCcycl
ETX
BCC
6.3.2
INPUT
Message structure for function ‘ME/V1’
Block access to parameter data
max. eff. length: 44 bytes
STX B2 , 6x , 1 = 112
, 4 , X1in
, X1out
, X2in
, X2out
, 0 ETX BCC
Block access to configuration data
max. eff. length: 66 bytes
STX B3 , 6x , 1 = 112 , 5 , X0 , X100 , XFail , Tfm , Tkref , 3 , C200 , C205 , C190 ETX BCC
6.3.3
CONTR
Message structure for function ‘General’
Block access to configuration data
max. eff. length: 36 bytes
STX B3 , 5x , 0
= 91 , 0 ,
4
,
C100 ,
C101 ,
C700 ,
C180 ETX BCC
Message structure for function ‘Set-point’
Block access to parameter data
max. eff. length: 56 bytes
STX B2 , 5x , 1
= 91 , 6 ,
W0
,
W100 ,
W2
,
Grw+ ,
Grw-
,
Grw2 ,
0
ETX
BCC
Message structure for function ‘Algo’
Block access to parameter data
max. eff. length: 72 bytes
STX B2 , 5x , 3 = 91 , 8
,
Xsh , Tpuls ,
Tm , Xsd
1
,
LW
, Xsd
2
, Xsh
1
,
Xsh
2
, 0 ETX
BCC
Message structure for function ‘Output variable’
Block access to parameter data
max. eff. length: 51 bytes
STX B2 , 5x , 4 = 91 , 5 ,
Ymin , Ymax ,
Y0
,
Yh
, LYh , 0 ETX
BCC
Message structure for function ‘Tuning’
Block access to parameter data
max. eff. length: 49 bytes
STX B2 , 5x , 5 = 91 , 4 , YOptm , dYopt , OXsd , Trig1 , 1 , POpt ETX BCC
Message structure for function ‘Paramset x’
Block access to parameter data
max. eff. length: 72 bytes
STX B2 , 5x , <6, 7> = 91 ,
8 , Xp1 , Tn1 , Tv1 ,
T1 , Xp2 , Tn2 , Tv2 ,
T2 , 0
ETX
BCC
Message structure for function ‘Start-up circuit’
Block access to parameter data
max. eff. length: 37 bytes
STX B2 , 5x , 10
= 91 , 3 ,
Ya
,
Wa
,
Tpa
,
0
ETX
BCC
6.3.4
ALARM
Message structure for function ‘General ‘
Block access to parameter data
max. eff. länge: 58 bytes
STX B2 , 7x , 0 = 46 , 6 , LimL , LimH , xsd_1 , LimLL , LimHH , LimHC ETX BCC
Block access to configuration data
max. eff. length: 36 bytes
STX B3 , 7x , 0 = 46 , 0 , 2 ,
C600
,
C601
ETX
BCC
Examples
9499 040 49411
