5.2.5 INPUT (FB no.: 60 ... 67 Type no.: 112)
All data which concern acquisition and processing of all input values (analog/digital) are grouped in function
block ‘INPUT’. The data are provided once per controller channel.
Process data
General Input processing of analog signals (Function no.: 0)
Code Des. R/W Type Description Range Rem.
00 Block R Block Block access (1, 3)
1 Input_x_Fail R ST1 Signal Input x Fail A
3 x1 R BCD Main variable
10 Block R Block Block access (13, 18)
13 INP1 R BCD Raw meas. value before meas. value correction
18 Function Type R INT Type no. of function block 112
Bem. A Statusbyte Input_X_Fail:
MSB LSB
D7 D6 D5 D4 D3 D2 D1 D0
Bit no. Name Allocation Status ‘0’ Status ‘1’
D0 INP1F Input 1 Fail no yes
D1...D5 ‘0’ Always ‘0’
D6 ‘1’ Always ‘1’
D7 Parity
Parameter a. configuration data
ME/V1 Measurement value INP1 : acquisition and processing (Function no.: 1)
Code Des. R/W Type Description Range Rem.
B2 41 X1
in
R/W BCD Measurement value correction X1 Input -999..9999
42 X1
out
R/W BCD Measurement value correction X1 Output -999..9999
43 X2
in
R/W BCD Measurement value correction X2 Input -999..9999
44 X2
out
R/W BCD Measurement value correction X2 Output -999..9999
B3 71 X0 R/W BCD Phys. value at 0% -999..9999
72 X100 R/W BCD Phys. value at 100% -999..9999
73 X
Fail
R/W BCD Substitute value at sensor fail -999..9999
74 T
fm
R/W BCD Filter time const. meas. Value processing. 0.0 .. 999.9
75 T
kref
R/W BCD Customer-specified TC 0...60 °C /32...140°F
76 C200 R/W INT Type: sensor type
Unit: unit
(T,H)
(Z)
0..xxy0
77 C205 R/W INT Fail: sensor fail behaviour
STk: TC source
XKorr: process value correction enable
(T)
(H)
(Z)
1..wxy0
78 C190 R/W INT Allocation of digital signals: controller off
w/w2
(Z)
(E)
0...00xy
Function block protocol
23 9499 040 49411
