Page 7

Mode Selections

Setting P

Setting Parameters

arameters

Setting Modes

Mode 1: R

Mode 1: Rate Measurement

ate Measurement

The DT-5TP operates in two modes. Mode 1 is programmed
when setting up rpm applications, and mode 5 is for
diagnostic testing:

Mode

Function

Application

Rate

Direct rpm

measurement

measurements

Self test

Diagnostic test of LED
display and input
circuitry

1. Apply any voltage between 9–35

VDC to terminals 1 and 2.
The display will show

2. Press mode and data set keys for at

least 5 seconds.

will then appear.

The DT-5TP can directly measure any rotational rate
speed. The two parameters listed below may need to be
changed during system set-up.

Factory

Parameter

Function

Setting

Range

Pulses per

1p/r

1–9999

revolution of
sensing system

Decimal point

none

0–4th place

Parameter 2: Decimal P

arameter 2: Decimal P

arameter 2: Decimal Point

oint

Here is how to change the parameter from 1 to 60 pulses
per revolution ("p/r"):

1. Set unit to mode 1.

(factory setting)

2. Press mode key.

3. Press shift key to select the

desired digit.

4. Press the increment key 6 times.

5. Press shift key.

6. Press the increment key 9 times.

Parameter 1 is now set for 60p/r.

1. Press mode key.

2. Press shift key to select position

of decimal point.

Parameter settings are now complete.

Press data set key to begin counting.

3. Press the increment key to select

the desired mode. The display will
shift between mode 1 and mode 5.

Parameter 1: Pulses per R

arameter 1: Pulses per R

arameter 1: Pulses per Revolution of

evolution of

Sensing Gear

4. Press mode key to activate mode 1

or mode 5.
