TECHNICAL DATA
8
33
IFC 070
www.krohne.com 11/2009 - 7311242200 - MA IFC 070 R02
8.3 Measuring accuracy
8.4 Dimensions and weights
Figure 8-2: X XX X = flow velocity [m/s], Y YY Y = deviation from the actual measured value [%]
1 with WATERFLUX 3000 water meter
2 with OPTIFLUX 2000 flow sensor
Compact version Compact version Compact version Compact version
a = 170 mm / 6.7"
b = 132 mm / 5.3"
c = 140 mm / 5.5"
Weight of converter = 1.9 kg / 4.2 lbs
Sizes of sensor can be found in the relevant
datasheet.
Remote version, signal converter Remote version, signal converter Remote version, signal converter Remote version, signal converter
b = 122 mm / 4.8"
c = 235 mm / 9.3"
H = 310 mm / 12.2"
Weight of converter = 3.3 kg / 7.3 lbs
