OPERATION
4
35
MFC 300
www.krohne.com 02/2013 - 4001086702 - AD MFC 300 FF R02 en
Units Index R/W Volume flow units: Volume flow units: Volume flow units: Volume flow units:
m³/s; m³/min; m³/h; m³/d; L/s; L/min; L/h; L/d; ML/d; cm³/s;
cm³/min; cm³/h; cm³/d; kL/min; kL/h; kL/d; mL/min; ft³/min =
CFM; ft3/h = CFH; ft³/d; gal/s; gal/min = GPM; gal/h; gal/d;
Mgal/d; ImpGal/s; ImpGal/min; ImpGal/h; ImpGal/d; bbl/s;
bbl/min; bbl/h; bbl/d
Uninitialized
Mass flow units: Mass flow units: Mass flow units: Mass flow units:
g/s; g/min; g/h; g/d; kg/s; kg/min; kg/h; kg/d; t/s; t/min; t/h;
t/d; lb/s; lb/min; lb/h; lb/d; st/s = (Ston/s); st/min = (Ston/min);
st/h = (Ston/h); st/d = (Ston/d); lt/s = (LTon/s); lt/min =
(Lton/min); lt/h = (LTon/h); lt/d = (LTon/d); MLB/H
Temperature units: Temperature units: Temperature units: Temperature units:
K; °C; °F; °R
Speed (velocity) units: Speed (velocity) units: Speed (velocity) units: Speed (velocity) units:
m/s; mm/s; m/h; km/h; knot; in/s; ft/s; yd/s
Density units: Density units: Density units: Density units:
kg/m³; Mg/m³; kg/dm³; g/cm³; g/m³; t/m³; kg/L; g/ml; g/L;
lb/in³; lb/ft³; lb/gal; STon/yd³; lb/ImpGal
Concentration units: Concentration units: Concentration units: Concentration units:
degAPI; % sol/wt; % sol/vol; % plato; degBrix; Baume 144;
Baume 145; % NaOH; % mass B; % vol B
Frequency units: Frequency units: Frequency units: Frequency units:
Hz
Resistor units: Resistor units: Resistor units: Resistor units:
Ohm
Other units: Other units: Other units: Other units:
%
Decimal Point R/W The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
0
Parameter Parameter Parameter Parameter
Subelement Access Description and settings Initial Value
