OPERATION
4
15
MFC 300
www.krohne.com 02/2013 - 4001086702 - AD MFC 300 FF R02 en
RESTART RESTART RESTART RESTART
Restart Restart Restart Restart
R/W Allows a manual restart to be initiated. Several degrees of
restart are possible. They are 1: Run, 2: Restart resource, 3:
Restart with defaults and 4: Restart processor.
Run
Setting:
Run / Resource / Defaults / Processor
RS_STATE RS_STATE RS_STATE RS_STATE
Resource State Resource State Resource State Resource State
R State of the function block application state machine. Standby
Setting:
Uninitialized / Start_Restart / Initialization / Online Linking /
Online / Standby / Failure
SET_FSTATE SET_FSTATE SET_FSTATE SET_FSTATE
Set Fault State Set Fault State Set Fault State Set Fault State
R/W Allows the fault state condition to be manually initiated by
selecting "Set".
Off
Setting:
Uninitialized / Off / Set
SHED_RCAS SHED_RCAS SHED_RCAS SHED_RCAS
Shed Remote Out Shed Remote Out Shed Remote Out Shed Remote Out
R/W Time duration at which to give up on computer writes to
function block RCAS locations. Shed from RCAS shall never
happen when SHED_RCAS = 0.
640000
Setting:
0...4294967295 in [1/32 ms]
SHED_ROUT SHED_ROUT SHED_ROUT SHED_ROUT
Shed Remote Out Shed Remote Out Shed Remote Out Shed Remote Out
R/W Time duration at which to give up on computer writes to
function block RCAS locations.
640000
Setting:
0...4294967295 in [1/32 ms]
TEST_RW TEST_RW TEST_RW TEST_RW
Test Read Write Test Read Write Test Read Write Test Read Write
R/W Read/write test parameter - used only for conformance
testing.
Note: Subelements "Value 1..15" have no function!
-
UPDATE_EVT UPDATE_EVT UPDATE_EVT UPDATE_EVT
Update Event Update Event Update Event Update Event
Mix This alert is generated by any change to the static data. -
Unacknowledged R/W A discrete enumeration which is set to "Unacknowledged"
when an alarm occurs, and set to "Acknowledged" by a write
from a human interface device or other entity which can
acknowledge that the alarm/event has been noticed.
Uninitialized
Setting:
Uninitialized / Acknowledged / Unacknowledged
Update State R A discrete enumeration which gives an indication of whether
the alert has been reported.
Uninitialized
Setting:
Uninitialized / Reported / Not reported
Time Stamp R The time when evaluation of the block was started and a
change in alarm/event state was detected that is unreported.
The time stamp value will be maintained constant until alert
confirmation has been received - even if another change of
state occurs.
Uninitialized
Setting:
MM / DD / YY (Month / Day / Year)
HH:MM:SS (Hour:Minute:Second)
Static Revision R The static revision of the block whose static parameter was
changed and is being reported. It is possible for the present
value of static revision to be greater than this because static
can be changed at any time.
0
Setting:
0…65535
Parameter Parameter Parameter Parameter
Subelement Access Description and settings Initial Value
