OPERATION

4

27

MFC 300

www.krohne.com

02/2013 - 4001086702 - AD MFC 300 FF R02 en

SENSOR_CAL_DATE

SENSOR_CAL_DATE

SENSOR_CAL_DATE

SENSOR_CAL_DATE

Sensor Calibration

Sensor Calibration

Sensor Calibration

Sensor Calibration

Date

Date

Date

Date

R

The date of the last measuring sensor calibration.

-

SENSOR_DIAMETER

SENSOR_DIAMETER

SENSOR_DIAMETER

SENSOR_DIAMETER

Sensor Diameter

Sensor Diameter

Sensor Diameter

Sensor Diameter

R

Pipe diameter of the measuring sensor.

-

SENSOR_SN

SENSOR_SN

SENSOR_SN

SENSOR_SN

Sensor Serial number

Sensor Serial number

Sensor Serial number

Sensor Serial number

R

The serial number of the measuring sensor.

-

SENSOR_TYPE

SENSOR_TYPE

SENSOR_TYPE

SENSOR_TYPE

Sensor Type

Sensor Type

Sensor Type

Sensor Type

R

The type of measuring sensor.

101

Setting:

101 (= Coriolis)

TRANSDUCER_

TRANSDUCER_

TRANSDUCER_

TRANSDUCER_

DIRECTORY

DIRECTORY

DIRECTORY

DIRECTORY

Transducer Directory

Transducer Directory

Transducer Directory

Transducer Directory

R

A directory that specifies the number and starting indices of

the transducers in the Transducer Block.

0

Setting:

0...65535

TRANSDUCER_

TRANSDUCER_

TRANSDUCER_

TRANSDUCER_

TYPE

TYPE

TYPE

TYPE

Transducer Type

Transducer Type

Transducer Type

Transducer Type

R

Identifies the transducer type. This is included in all the 4

views as per definition given in the standard pressure

transducer block given by FF.

Other

XD_ERROR

XD_ERROR

XD_ERROR

XD_ERROR

Transducer Error

Transducer Error

Transducer Error

Transducer Error

R

One of the transducer error codes defined in the FF

Transducer Specifications in "Block Alarm Subcodes".

0

Setting:

16: Unspecified error (An error has occurred that was not

identified.)

17: General error (An error has occurred that could not be

classified as one of the errors below.)

18: Calibration error (An error occurred during calibration of

the device or a calibration error has been detected during

operation of the device.)

19: Configuration error (An error occurred during

configuration of the device or a configuration error has been

detected during operation of the device.)

20: Electronics Failure (An electronic component has failed.)

21: Mechanical Failure (An mechanical component has failed.)

22: I/O Failure (An I/O failure has occurred.)

23: Data Integrity Error (Indicates that data stored within the

system may not longer be valid due to NVM checksum failure.

Data verify after write failure, etc.)

24: Software Error (The software has detected an error. This

could be caused by an improper interrupt service routine, an

arithmetic overflow, a watchdog timer, etc.)

25: Algorithm Error (The algorithm used in the Transducer

Block produced an error. This could be due to an overflow,

data reasonableness failure, etc.)

FLOW_DIRECTION

FLOW_DIRECTION

FLOW_DIRECTION

FLOW_DIRECTION

Flow Direction

Flow Direction

Flow Direction

Flow Direction

R/W

Setting:

Normal

Reverse

Normal

Parameter

Parameter

Parameter

Parameter
Subelement

Access

Description and settings

Initial Value
