4
OPERATION
34
MFC 300
www.krohne.com 02/2013 - 4001086702 - AD MFC 300 FF R02 en
UPDATE_EVT UPDATE_EVT UPDATE_EVT UPDATE_EVT
Update Event Update Event Update Event Update Event
R This alert is generated by any change to the static data. -
Unacknowledged R A discrete enumeration which is set to "Unacknowledged"
when an alarm occurs, and set to "Acknowledged" by a write
from a human interface device or other entity which can
acknowledge that the alarm/event has been noticed.
Uninitialized
Setting:
Uninitialized / Acknowledged / Unacknowledged
Alarm State R A discrete enumeration which gives an indication of whether
the alert is active and whether it has been reported.
Uninitialized
Setting:
Uninitialized / Clear - reported / Clear - not reported / Active -
reported / Active - not reported
Time Stamp R The time when evaluation of the block was started and a
change in alarm/event state was detected that is unreported.
The time stamp value will be maintained constant until alert
confirmation has been received - even if another change of
state occurs. Time stamp records the time when parameter
was updated.
Uninitialized
Setting:
MM / DD / YY (Month / Day / Year)
HH:MM:SS (Hour:Minute:Second)
Static Revision R The static revision of the block whose static parameter was
changed and is being reported. It is possible for the present
value of static revision to be greater than this because static
can be changed at any time.
0
Relative Index R The OD index of the static parameter whose change caused
this alert, minus the FB starting index. If the update event was
caused by a write to multiple parameters at the same time,
then this attribute will be zero.
0
XD_SCALE XD_SCALE XD_SCALE XD_SCALE
Transducer Scale Transducer Scale Transducer Scale Transducer Scale
R/W The high and low scale values, engineering units code and
number of digits to the right of the decimal point used with the
value obtained from the transducer for a specified channel.
Note: Note: Note: Note:
W = Writeable only by setting "OOS" in MODE_BLK
-
EU_100
Engineering Unit
100
R/W The engineering unit value which represents the upper end of
range of the associated block parameter.
100
EU_0
Engineering Unit 0
R/W The engineering unit value which represents the lower end of
range of the associated block parameter.
0
Parameter Parameter Parameter Parameter
Subelement Access Description and settings Initial Value
