4

OPERATION

30

MFC 300

www.krohne.com

02/2013 - 4001086702 - AD MFC 300 FF R02 en

Time Stamp

R

The time when evaluation of the block was started and a

change in alarm/event state was detected that is unreported.

The time stamp value will be maintained constant until alert

confirmation has been received - even if another change of

state occurs.

Uninitialized

Setting:

MM / DD / YY (Month / Day / Year)

HH:MM:SS (Hour:Minute:Second)

Subcode

R

An enumeration specifying the cause of the alert to be

reported.

Other

Setting:

Other / Block Configuration / Link Configuration / Simulation

Active / Local Override / Device Fault State / Device

Maintenance / Input Failure / Output Failure / Memory

Failure / Lost Static Data / Lost NV Data / Readback Check /

Maintenance Needed / Power Up / Out Of Service

Value

R

The value of the associated parameter at the time the alert

was detected.

0

Setting:

0...255

CHANNEL

CHANNEL

CHANNEL

CHANNEL

Channel

Channel

Channel

Channel

R/W

The number of the logical hardware channel that is connected

to this I/O block. This information defines the transducer to be

used going to or from the physical world.

Note:

Note:

Note:

Note:

W = Writeable only by setting "OOS" in MODE_BLK

Uninitialized

Setting:

1 (Mass Flow in kg/s)

2 (Density in kg/m

3

)

3 (Tube Temp. in °C)

4 (Flow Velocity in m/s)

5 (Volume Flow in m

3

/s)

6 (Conc. Mass Flow 1 in kg/s)

7 (Conc. Mass Flow 2 in kg/s)

8 (Conc. Volume Flow 1 in m

3

/s)

9 (Conc. Volume Flow 2 in m

3

/s)

10 (Concentration 1 in %sol/wt)

11 (Concentration 2 in %sol/wt)

12 (2 Phase Signal in %)

13 (Sensor Average in %)

14 (Sensor Deviation in %)

15 (Drive Level in %)

16 (Tube Frequency in Hz)

17 (Strain MT in Ohm)

18 (Strain IC in Ohm)

19 (Electronic Temp. in °C)

FIELD_VAL

FIELD_VAL

FIELD_VAL

FIELD_VAL

Field Value

Field Value

Field Value

Field Value

R

Raw value of the field device in percent of the PV range, with a

status reflecting the transducer condition, before signal

characterization (L_TYPE) or filtering (PV_FTIME).

-

Status

R

Actual Status is displayed.

-

Value

R

Actual Field Value

-

Parameter

Parameter

Parameter

Parameter
Subelement

Access

Description and settings

Initial Value
