20
UFM 3030
Function 3.05.09
3.05.08 PULSE RATE Pulse rate (frequency) value for 100 % scale
pulse/s, pulse/hr, pulse/min
Range: 1 pulse/hr through 2000 pulse/s
3.05.09 PULSE/UNIT Pulse value per volume unit for totalisation
pulse/m³, pulse/l, pulse/US.Gal, pulse/bbl,
free user definable unit
3.05.10 PULSE/UNIT Pulse value per heat energy unit for totalisation
Pulse/MJ, pulse/Gcal, pulse/Mcal, pulse/GJ
3.05.11 PULS WIDTH Pulse width for frequencies ≤ 10 Hz
25 ms, 50 ms, 100 ms, 200 ms, 500 ms
3.06.00 DIG INPUT Submenu 3.06.00 Digital input
3.06.01 FUNCTION Function of digital input
OFF (switched off)
RST TOTAL (reset display Totalizer)
RST ERROR (reset error messages)
FORCE ZERO (set outputs to minimum values)
BATCH (start batch)
3.07.00 USER DATA Submenu 3.07.00 User data
3.07.01 LANGUAGE Language for display texts
GB/USA (English)
D (German)
F (French)
3.07.02 ENTRY CODE Entry code for setting mode
NO (entry with key only)
YES (entry with key and code 1, factory set on 9 x key, see
Function 3.07.03)
3.07.03 CODE 1 Code 1
Press any 9-keystroke combination and then press the same
combination again. Each keystroke is acknowledged by "Ж" in the
display. If both combinations are equal, "CODE OK" appears and
the new code can be stored, else "WRONG CODE" appears and
the desired code has to be entered again.
3.07.04 LOCATION Tag name setting
Free settable tag for identification, maximum 10 characters.
Characters assignable to each place: A..Z / blank character / 0..9
Factory setting: KROHNE
3.07.05 UNIT TEXT Text for user-defined unit
Definition: volume/time
Characters assignable to each place: A..Z / blank character / 0..9
Fraction bar "/" in 5th place is unalterable
Factory setting: XXXX/YYY
3.07.06 UNIT VOL User-defined unit volume
Quantity of user-defined volume per m³.
Range: 10-5 through 107
Factory setting: 1
3.07.07 UNIT TIME User-defined unit time
Amount of user-defined time in seconds
Range: 10-5 through 107
Factory setting: 1
3.07.08 RST ENABLE Enable Totalizer reset
NO (Totalizer reset disabled)
YES (Totalizer reset enabled)
