RKW 300W 060110
3
Remote Control ON/OFF:
"High", 2.4V to 24V (or open), unit OFF- Fan Off ; "Low", 0.0V to 0.4V (or closed), unit ON.
Source current is 1.6mA maximum at low level, and sink current is 1.0 mA maximum at high
level. The ±RC terminals are isolated from the a-c input terminal and the DC output terminals.
When remote ON/OFF is not in use, ±RC terminals must be shorted (use shorting link sup-
plied) for unit to operate.
Operating Temperature:
-10 to 65°C (see figures 2 and 3)
Startup Temperature
-20 to -10°C (see Figure 2)
Storage Temperature:
-30°C to +75°C
Withstanding voltage : (at 15-35°C
ambient, 10-85% relative humidity)
2000Va-c for 1 minute. Cutout current is 20mA
Between input and ground
500Va-c for 1 minute. Cutout current is 100mA
Between output and ground
3000Va-c for 1 minute. Cutout current is 20mA
Between input and output
Insulation Resistance: (at 15-35°C
ambient, 10-85% relative humidity)
Between output and ground, input and ground, and input and output, 100 Megohms minimum
(500Vdc)
Humidity:
10% to 95% relative humidity, noncondensing, Wet Bulb tem-
perature
operating and non-operating
Vibration:
5-10 Hz., 10mm amplitude,
10-200 Hz., acceleration 64.3ft./s
2
( 19.6m/s
2
) (2g)
non-operating, 1 hr. on each
of 3 axes, sweep time 10
minutes
Shock:
(non-operating, 1/2 sine pulse,
three shocks on each axis, Power
Supply is fixed on its bottom side)
Acceleration: 964.6ft./s
2
(294m/s
2
) (30g),
Pulse Duration: 11ms ± 5 msec
Safety:
All units designed to meet UL1950, CSA Electrical Bulletin 22.2 No.950-95 (certified by UL),
and TÜV Rheinland EN60950 (ambient temp.50°C max., 3.3V Model: 40°C max). Meets
Creepage and Clearance requirements of Dentori, Appendix 8. RKW 300W units are CE
marked per the Low Voltage Directive (LVD), 73/23/EEC and 93/68/EEC. [The standards do
not apply with DC input operation.]
EMI Conducted:
Designed to meet FCC Class B, VCCI-Class B, EN55011-B, EN55022-B.
EMI Radiated:
Designed to meet FCC Class B, VCCI-Class B, EN55011-B, EN55022-B.
Input current harmonics:
Designed to meet EN61000-3-2.
Immunity:
EN61000-6-2:1999
ESD immunity:
Designed to meet EN61000-4-2, level 4.
normal operation
Fast transient burst immunity:
Designed to meet EN61000-4-4 level 3.
normal operation
Surge immunity:
Designed to meet EN61000-4-5, level 4.
no damage
Power frequency magnetic field
immunity:
Designed to meet EN61000-4-8, level 4.
normal operation
Radiated field immunity:
Designed to meet EN61000-4-3 level 3.
normal operation
Conducted noise immunity:
Designed to meet EN61000-4-6 level 3.
normal operation
Voltage dips interruptions and
variations:
Designed to meet EN61000-4-11.
normal operation
Dimensions:
3.62 in. (92 mm) x 3.15 in. (80 mm) x 6.89 in. (175 mm)
Mounting:
Four No. M4 tapped holes on the sides and the bottom
Maximum Screw Penetration:
0.24 in. (6 mm)
Cooling:
Forced air flow - one fan
Frame Material/Cover Material:
Steel
Weight
3.3 lbs. (1.5Kg) typ., 3.97 lbs.(1.8 Kg) maximum
TABLE 2. POWER SUPPLY RATINGS AND SPECIFICATIONS (CONTINUED)
SPECIFICATION
DESCRIPTION
