4
228-1699 REV 2 093013
KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000 FAX (718) 767-1102
http://www.kepcopower.com email: [email protected]
IV — ACCESSORIES
See Table 3.
V — SAFETY
See Table 4
TABLE 3. ACCESSORIES
ITEM FUNCTION PART NUMBER
Mating Connector, Trigger Mates with Trigger port. 142-0527 (Kepco)
SP2501 (CUI Stack)
IEEE 1118 (BITBUS)
Mating connector Allows connection to IEEE 1118 (BITBUS) port. 142-0485 (Kepco)
KMDLA-5P (Kycon Inc.)
IEEE 488 Cable, (1 meter long) Connects BOP-GL power supply to GPIB bus. SNC 488-1
IEEE 488 Cable, (2 meter long) Connects BOP-GL power supply to GPIB bus. SNC 488-2
IEEE 488 Cable, (4 meter
longs) Connects BOP-GL power supply to GPIB bus. SNC 488-4
Line Cord (250V, 20A) Provides connection to a-c mains via Nema 6-20P connector. 118-1087
Line Cord (250V, 20A) Provides connection to a-c mains via Nema L6-20P locking type con-
nector.
118-1088
RS 232 Cable Kit Contains RJ11 to RJ45 Patch cord, RJ 45 Patch cord, two RS 232
adapters, one with male pins to connect to DTE equipment and one
with female pins to connect to a PC (personal computer), two RS 232
Loop Back test Connectors (one 6-pin and one 8-pin) to test RS 232
communication and aid in isolating RS 232 communication problems.
KIT 219-0436
RS 232 Adapter (Male pins) Allows RS 232 port to be connected to DTE equipment. (Supplied in
KIT 219-0436.) 142-0487
(L-COM RA098M)
RS 232 Adapter (Female pins) Allows RS 232 port to be connected to a PC (personal computer). (Sup-
plied in KIT 219-0436.) 142-0506
(L-COM RA098F)
15-pin DSUB Connector Mating connector for Analog input connector A2A5J6
Dsub 15 pin hood
Dsub 15 pin male
108-0374
(Tyco-Amp 207470-1)
142-0449
(Amphenol 17S-DA15P)
IDC 6-pin connector Mating connector for RS-232 PORT, connector A1J5 and PROTEC-
TION EXT. PORT, connector A2A5J7 142-0536
(Amphenol 5-555176-3)
IDC 8-pin plug Mating connector for PAR/SER PROTECT PORT (IN and OUT) con-
nectors. 142-0535
(Amphenol 5-555176-3)
Slides Allows easy withdrawal of unit from rack (Model CS 04 includes slides,
brackets, all mounting hardware and installation instructions.)
CS 04
Heat Sink Provides adequate cooling for calibration sense resistors. 136-0451
TABLE 4. SAFETY SYMBOLS
SYMBOL MEANING
CAUTION: RISK OF ELECTRIC SHOCK.
CAUTION: REFER TO REFERENCED PROCEDURE.
WARNING INDICATES THE POSSIBILITY OF BODILY INJURY OR DEATH.
CAUTION INDICATES THE POSSIBILITY OF EQUIPMENT DAMAGE.
!
