Rear view detail "a – KEPCO BOP-GL 1KW Quick Start Guide User Manual
Page 15
093013
228-1699 REV 2
15
KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000 FAX (718) 767-1102
http://www.kepcopower.com email: [email protected]
FIGURE 6. BOP 1KW OUTLINE DIMENSIONS (SHEET 2 OF 2)
SLIDES TRAVEL DISTANCE: 23.000 [584.2]
22.000 [558.79]
SEE NOTE 6.
REAR VIEW
DETAIL "A"
SEE DETAIL "A".
