KANOMAX 2211 Handheld IAQ Monitor - Manual (Page 10)

5
①
2.2 Connecting Probe
※ Make sure that the power is OFF when connecting or
Disconnecting Probe/Probe cable.
①
Main Body connector and probe connector only fit one way.
②
Push-in the connector until you hear click.
※ DO NOT FORCE to connect Probe,
it may cause a serious damage to the instrument.
2.3 Disconnecting Probe
※ Make sure that the power is OFF when connecting or disconnecting.
① Pull up the lock ring of Probe.（see chart ①-Ａ）
② Pull out Probe from Main Body
with the lock ring up (see chart ②).
※
DO NOT rotate Probe while connected,
it may cause a serious damage to the instrument.
Probe Terminal
②
①
Ａ
①
②
